Datasheet

Technische Änderungen und Irrtümer vorbehalten. Subject to technical changes and errors.
Datum / Date: 03.2011 AS2 Revision: 1.0 Seite 1 von 1
Datenblatt / Data Sheet
Artikelnr.
Diameter
Length Color Volts AC/DC Base
Design Current
(mA)
Wave Length
(nm) Lumens Life time (h)
View
Angle
70112322 T5.5*28mm Red 12V T5.5 17±2mA 620-630 0.8 lm 30K(h) 60°
70112326 T5.5*28mm Red 24-28V T5.5 16±2mA 620-630 0.8 lm 30K(h) 60°
70112336 T5.5*28mm Green 12V T5.5 16±2mA 515-525 2 lm 30K(h) 60°
70112340 T5.5*28mm Green 24-28V T5.5 17±2mA 515-525 2.1 lm 30K(h) 60°
70112350 T5.5*28mm Blue 12V T5.5 17±2mA 465-475 0.3 lm 30K(h) 60°
70112354 T5.5*28mm Blue 24-28V T5.5 16±2mA 465-475 0.3 lm 30K(h) 60°
70112364 T5.5*28mm Amber 12V T5.5 17±2mA 590-600 0.4 lm 30K(h) 60°
70112368 T5.5*28mm Amber 24-28V T5.5 16±2mA 590-600 0.4 lm 30K(h) 60°
70112376 T5.5*28mm White 6V T5.5 16±2mA (K)5000-6000 2.1 Im 30K(h) 60°
70112378 T5.5*28mm White 12V T5.5 16±2mA (K)5000-6000 2.1 Im 30K(h) 60°
70112382 T5.5*28mm White 24-28V T5.5 17±2mA (K)5000-6000 2.1 Im 30K(h) 60°
70112384 T5.5*28mm White 36V T5.5 16±2mA (K)5000-6000 2.1 Im 30K(h) 60°
70112386 T5.5*28mm White 48V T5.5 16±2mA (K)5000-6000 2.1 Im 30K(h) 60°
70112388 T5.5*28mm White 60V T5.5 16±2mA (K)5000-6000 2.1 Im 30K(h) 60°
T5.5 Slide Base Lamp
