Datasheet

Technische Änderungen und Irrtümer vorbehalten. Subject to technical changes and errors.
Datum / Date: 03.2011 AS2 Revision: 1.0 Seite 1 von 1
Datenblatt / Data Sheet
Artikelnr.
Diameter
Length Color
Volts
AC/DC Base
Design Current
(mA)
Wave Length
(nm) Lumens
Life time
(h)
View
Angle
70112252 T5.5*22mm Red 12V T5.5K 17±2mA 620-630 0.8 lm 30K(h) 60°
70112256 T5.5*22mm Red 24-28V T5.5K 16±2mA 620-630 0.8 lm 30K(h) 60°
70112266 T5.5*22mm Green 12V T5.5K 16±2mA 515-525 2 lm 30K(h) 60°
70112270 T5.5*22mm Green 24-28V T5.5K 17±2mA 515-525 2.1 lm 30K(h) 60°
70112280 T5.5*22mm Blue 12V T5.5K 17±2mA 465-475 0.3 lm 30K(h) 60°
70112284 T5.5*22mm Blue 24-28V T5.5K 16±2mA 465-475 0.3 lm 30K(h) 60°
70112294 T5.5*22mm Amber 12V T5.5K 17±2mA 590-600 0.4 lm 30K(h) 60°
70112298 T5.5*22mm Amber 24-28V T5.5K 16±2mA 590-600 0.4 lm 30K(h) 60°
70112306 T5.5*22mm White 6V T5.5K 16±2mA (K)5000-6000 2.1 Im 30K(h) 60°
70112308 T5.5*22mm White 12V T5.5K 16±2mA (K)5000-6000 2.1 Im 30K(h) 60°
70112312 T5.5*22mm White 24-28V T5.5K 17±2mA (K)5000-6000 2.1 Im 30K(h) 60°
70112314 T5.5*22mm White 36V T5.5K 16±2mA (K)5000-6000 2.1 Im 30K(h) 60°
70112316 T5.5*22mm White 48V T5.5K 16±2mA (K)5000-6000 2.1 Im 30K(h) 60°
70112318 T5.5*22mm White 60V T5.5K 16±2mA (K)5000-6000 2.1 Im 30K(h) 60°
T5.5K Slide Base Lamp
