Table Of Contents

Page 6

W1+W3

7/16”/

11mm

7/16”/ 11mm

W1+W3

D

A1

A1

5a

The anchor must be

sunk at least 3/8"/10 mm

into the plaster coating

5b

3/8”/ 10 mm

Drill with 5/32” \ 4mm drill bit

First use 1/4” \ 6mm drill bit

Afterwards use 3/8” \ 10mm drill bit

4 x 360°

2 x 360°

2

1

2

1

W2

5/32” \ 4mm

2.75” \ 70mm

3/8” \ 10mm

2.75” \ 70mm

2

2.75” \ 70mm

1/4” \ 6mm

1

FULL TIGHTENING

D

FULL TIGHTENING
