OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
DAT4 1
RCVDS05 only answers ACK or NACK.
Example : STX OFFS ADR 79H 06 0 3AH 1 CHKS
+OFFS
The computer will update the sharpness to the value 3AH and write it into the
EEPROM for the current selected source
BLOCK_DEL 73H
Set all the settings of the indicated source to default in the EEPROM.
Computer to RCVDS : STX OFFS ADR 73H 0 DAT2 0 0 CHKS
+OFFS
DAT1 0
DAT2 the indicated source number(1 to 20)
DAT3 0
DAT4 0
RCVDS05 only answers ACK or NACK.
The default values are :
prefading 3CH (0dB)
tint (hue) 3FH (50%)
saturation 3FH (50%)
shapness E1H (0dB)
(These values are the same after starting up the RCVDS05 for the first time)
FORCE_TOGGLE 51H
Forces a toggle to the desired state
Computer to RCVDS : STX OFFS ADR 51H DAT1 0 0 DAT4 CHKS
+OFFS
DAT1 0BH "BEEP" on/off
DAT2 0
DAT3 0
DAT4 0 = switched off
1 = switched on
RCVDS05 only answers ACK or NACK.
