3.Physical Installation
Remote Control overview
ON/OFF
HOME
OK
ARROW RIGHT
ARROW UP
ARROW LEFT
ARROW DOWN
LED INDICATION
BATTERY COMPARTMENT
IR LED'S
Basic Remote Command
result
RCU Lite
action
start the projector press "on/off"
turn off the projector press "on/off"
>
show main menu on screen press "home"
move through menu press "arrow keys"
select button press "ok"
select and return to previous menu press "ok"
return to previous menu without
selecting
press "home"
clear OSD Lite of screen press "home"
