2.General
3. Take out the projector.
After unpacking let the projector acclimatizes to a room temperature higher then 10°C (50°F) and lower
then 40°C (104°F). Neglecting this may result in a start up failure of the Light Processor Unit.
Save the original shipping carton and packing material, they will be necessary if you ever have to ship your
projector. For maximum protection, repack your projector as it was originally packed at the factory.
The lens is delivered in a separate box.
2.3 Initial inspection
General
Before shipment, the projector was inspected and found to be free of mechanical and electrical defects. As soon as the
projector is unpacked, inspect for any damage that may have occurred in transit. Save all packing material until the inspection
is completed. If damage is found, file claim with carrier immediately. The Barco Sales and Service office should be notified as
soon as possible.
Box content
After unpacking the projector it is recommended to check if all following items where included:
•
Three power cords
•
One DVI-D to HDMI cable
•
CD (Contents has this installation manual)
•
One Safety manual
•
One remote control unit (RCU)
•
Two AAA size batteries for the RCU
Two lamps are mounted inside the lamp house at delivery. The projector lenses are not included in the
package of the projector.
