PJWU-101B User manual
Barco nv Projection Division Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.82.11 Fax: +32 56.36.883.86 Support: www.barco.com/esupport Visit us at the web: www.barco.
Changes Barco provides this manual ’as is’ without warranty of any kind, either expressed or implied, including but not limited to the implied war- ranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time without notice. This publication could contain technical inaccuracies or typographical errors.
TABLE OF CONTENTS 1. SAFETY 1 1.1 General considerations 1 1.2 Important safety instructions 2 2. GENERAL 5 2.1 Installation requirements 5 2.2 Unpacking the projector 6 2.3 Initial inspection 7 2.4 Projector configurations 8 2.5 Projector air inlets and outlets 11 2.6 Installation process overview 11 3. PHYSICAL INSTALLATION 12 3.1 Remote control unit (RCU) 12 3.2 Lenses 14 3.3 Connecting the projector with the power net 17 3.4 Alignment of a table mounted projector 19 3.
TABLE OF CONTENTS 5. GETTING STARTED 29 5.1 RCU & Local keypad 29 5.2 Remote Control and OSD Lite on Screen 29 5.3 Power on projector 31 5.4 Switching to standby 31 5.5 Power off projector 31 5.6 Range of effective remote control signal reception 32 5.7 Source selection 32 5.8 Changing OSD language 33 5.9 Adjusting the lens by horizontal and vertical lens shift 33 5.10 Introduction the OSD Lite on screen 34 6. ADVANCED OSD MENU 35 6.1 How to activate the Advanced OSD menu 35 6.
TABLE OF CONTENTS 8. IMAGE 40 8.1 Image menu overview 40 8.2 Contrast 41 8.3 Brightness 41 8.4 Sharpness 42 8.5 Noise Reduction 42 8.6 Color Temperature 42 8.7 Input Balance 43 8.8 Aspect Ratio 45 8.9 Timings 46 8.10 Auto Image 47 9. LAYOUT 48 9.1 Layout menu overview 48 9.2 Zoom 49 9.3 Main Select 49 9.4 PIP Select 50 9.5 PIP Position 50 9.6 PIP 50 10. LAMP 51 10.1 Lamp menu overview 51 10.2 Mode 52 10.3 Lamps 52 10.4 High Altitude Mode 53 10.5 Power 53 10.
TABLE OF CONTENTS 11. ALIGNMENT 54 11.1 Alignment menu overview 54 11.2 Adjusting screen orientation 55 11.3 Rear Projection 55 11.4 Ceiling Mode 56 11.5 Lens Control 56 11.6 Keystone 56 11.7 Dynamic Contrast 56 11.8 Gamma 57 11.9 Internal Patterns 57 11.10 Color Space 57 11.11 Lens To Midposition 57 12. CONTROL 58 12.1 Control menu overview 58 12.2 Eco Network Power 59 12.3 Network 59 12.4 Menu Position 60 12.5 Start Up Logo 61 12.6 Start Up Chime 61 12.
TABLE OF CONTENTS 14. MAINTENANCE 64 14.1 Lamp Replacement 64 14.2 Replace the filter (for inlet Ventilation) 66 14.3 Clean the dust filter(for outlet Ventilation) 69 14.4 Cleaning the lens 69 14.5 Cleaning the exterior of the projector 70 14.6 Simple troubleshooting 70 15. PROJECTOR SPECIFICATION 72 15.1 Specifications 72 15.2 STANDARD SOURCE FILES 73 15.3 Dimension 74 16. ENVIRONMENTAL INFORMATION 75 16.1 Disposal information 75 16.2 Rohs compliance 75 16.
1.SAFETY 1. SAFETY About this chapter Read this chapter attentively. It contains important information to prevent personal injury while installing and using a PJWU101B projector. Furthermore, it includes several cautions to prevent damage to the PJWU-101B projector. Ensure that you understand and follow all safety guidelines, safety instructions and warnings mentioned in this chapter before installing your PJWU-101B projector.
1.SAFETY Users definition Throughout this manual, the term SERVICE PERSONNEL refers to persons having appropriate technical training and experience necessary to be knowledgeable of potential hazards to which they are exposed (including, but not limited to HIGH VOLTAGE ELECTRIC and ELECTRONIC CIRCUITRY and HIGH BRIGHTNESS PROJECTORS) in performing a task, and of measures to minimize the potential risk to themselves or other persons.
1.SAFETY and possible injury to the user. • It is hazardous to operate without lens or shield. Lenses, shields or ultra violet screens shall be changed if they have become visibly damaged to such an extent that their effectiveness is impaired. For example by cracks or deep scratches. • Warning: Protection from ultraviolet radiation: Do not look directly in the light beam. The lamp contained in this product is an intense source of light and heat.
1.SAFETY • Ensure that nothing can be spilled on, or dropped inside the projector. If this does happen, switch off and unplug the mains supply immediately. Do not operate the projector again until it has been checked by qualified service personnel. • Do not block the projector cooling fans or free air movement around the projector. Loose papers or other objects may not be nearer to the projector than 30 cm (12") on any side. • Do not use this equipment near water.
2.General 2. GENERAL About this chapter Read this chapter before installing your PJWU-101B projector. It contains important information concerning installation requirements for the PJWU-101B projector, such as minimum and maximum allowed ambient temperature, humidity conditions, required safety area around the installed projector, required power net, etc.
2.General Main Power requirements The PJWU-101B projector operates from a nominal mono phase power net with a separate earth ground PE. Projector PJWU-101B Power requirements AC INPUT 100-130V 11.6A 50/60Hz AC INPUT 200-240V 5.6A 50/60Hz The power cord required to connect the projector with the power net is delivered with the projector. Projector weight Do not underestimate the weight of the PJWU-101B projector. The projector weights about ±33 kg (±72.75lb.) without lens.
2.General 3. Take out the projector. After unpacking let the projector acclimatizes to a room temperature higher then 10°C (50°F) and lower then 40°C (104°F). Neglecting this may result in a start up failure of the Light Processor Unit. Save the original shipping carton and packing material, they will be necessary if you ever have to ship your projector. For maximum protection, repack your projector as it was originally packed at the factory. The lens is delivered in a separate box. 2.
2.General Mechanical check This check should confirm that there are no broken knobs or connectors, that the cabinet and panel surfaces are free of dents and scratches, and that the operating panel is not scratched or cracked. The Barco Sales and Service office should be notified as soon as possible if this is not the case. 2.4 Projector configurations The different configurations Depending on the installation the projector can be mounted in different ways, the different configurations are: 1.
2.General Rear projection The projector is installed, either in a table mount or ceiling mount configuration, at the other side of the screen opposite the audience. AUDIENCE BACKSTAGE SCREEN R/C R/T FLOOR Rear projection Positioning the projector A SH PD SH SCREEN SW B CD B CD SCREEN SW SCREEN FLOOR Positioning projector The projector should be installed at right angles (horizontally and vertically) to the screen at a distance PD.
2.General Shift range The lens can be shifted with respect to the DMD (P) which result in a shifted image on the screen (Off-Axis). A 100% shift means that the centre point of the projected image is shifted by half the screen size. In other words, the centre point of the projected image falls together with the outline of the image in an On-Axis projection. Due to mechanical and optical limitations it’s recommended to keep the shift values within the field of view (F) as illustrated below.
2.General 2.5 Projector air inlets and outlets Ventilation inlet: The internal cooling fan draws cool air from the ventilation inlet into the projector. Ventilation outlet: The hot air generated inside the projector is dispersed through the ventilation slot. Make sure the ventilation slot is free from obstruction. Ventilation inlet Ventilation inlet Ventilation outlet 2.
3.Physical Installation 3. PHYSICAL INSTALLATION About this projector This chapter describes how the mechanical set up of the projector has to be done and how to realize the electrical connections. Overview • • • • • Remote control unit (RCU) Lenses Connecting the projector with the power net Alignment of a table mounted projector Mounting the ceiling mount 3.1 Remote control unit (RCU) Introduction Remove the cover by sliding it in the direction indicated by the arrow.
3.
3.Physical Installation 3.2 Lenses Available lenses for the PJWU-101B projector projector • • • • R9832760 : J lens (1,85-2,4 : 1) - Standard Lens R9832761 : J lens (1,56-1,86 : 1) - Short Throw Lens R9832762 : J lens (2,4-4,0 : 1) - Longer Zoom lens R9832763 : J lens (0,84-1,03 : 1) - Extreme Wide Angle Lens Projection lenses are optional accessories. Please contact your local dealer to acquire the projection lens that suits your need most. How to install the lens 1.
3.Physical Installation 2. Counterclockwise rotate the lens to the end then you can follow the forward direction to remove the lens. CAUTION: Never transport the projector with a Lens mounted in the Lens Holder. Always remove the Lens before transporting the projector. Neglecting this can damage the Lens Holder and Prism. It’s recommended to place the Lens caps of the original Lens packaging, back on both sides of the removed Lens to protect the optics of the Lens.
3.Physical Installation Lens Shift In addition to using the adjustable feet to adjust projection angle, you can also use the Lens Shift function to adjust the projected image. • Moving the lens vertically The distance of vertical lens movement is +100% , -100% of half the screen height in both directions.For instance, if you are using a 80" × 50" screen, you will be able to move the image upwards no more than 25'' or downwards no more than 25''.
3.Physical Installation 3.3 Connecting the projector with the power net CAUTION: Use only the power cord provided with the projector. 1. Select correct voltage 2. Ensure that the power switch stands in the ’0’ (OFF) position . 3. Connect the female side of the power cord with the power input socket of the projector . 4. Secure the power plug by locking the plug holder clamp.
3.Physical Installation 5. Connect the male side of the power cord to the local power net. For Europe and Korea For USA Caution: Ensure that the power net meets the power requirements For China of the projector. WARNING: Do not attempt operation if the AC supply and cord are not within the specified voltage and power range.
3.Physical Installation 3.4 Alignment of a table mounted projector How to align the projector 1. Place the projector in the desired location. Take into account the zoom range of the used lens and the size of the screen. 2. Project one of the internal hatch patterns on the screen. 3. Turn the adjustable feet in or out until the projected hatch pattern has a perfect rectangle shape and is leveled. SCREEN When this is achieved, the projector is set horizontal and vertical at right angles to the screen.
3.Physical Installation 3.5 Mounting the Ceiling mount Necessary tools Open wrench 17 mm How to mount 1. Turn the projector upside down. 2. Adjustment knob to the back of the projector. Make sure that the mounting holes matches the holes in the projector. 3. Insert a bolt in each corner and turn in these bolts. Mounting bracket screw 3 holes of M8*15 Mounting bracket screw 6 holes of M6*15 125.50 155 65.90 199.70 160 532 105 305 220 152.
4. Input & Communication 4. PROJECTOR PARTS AND FUNCTIONS Overview • • • • • Projector front view Projector Rear view Input and Communication Status lights of LED Connecting the projector to other devices 4.1 Projector front view Power switch I -> ON O -> OFF Infrared receiver Power inlet Lens Adjustable foot Adjust the height and angle of the projector with the adjustable foot Ventilation slot The hot air generated inside the projector is dispersed through the ventilation slot.
4. Input & Communication 4.3 Input and Communication 2 1 6 3 4 7 5 8 1. 10/100 BASE-T Ethernet port The projector can be connected to a LAN (local area network) using the Ethernet port on the communication interface. Once connected to the LAN, users are capable of accessing the projector from any location, inside or outside (if allowed) their company network using the control software: Projector Toolset.
4. Input & Communication Advantages of using RS232 serial communication: • • • • • easy adjustment of the projector via PC (or MAC). allow storage of multiple projector configurations and set ups. wide range of control possibilities. sending data to the projector (update). copying data from the projector (backup).
4. Input & Communication 8. RGBHV/YUV2 Optional multi purpose input which can be inserted in the free slots. Input Signal RGBHV Composite Video G/Y G Y RS232 input (Sub-D) port B/Pb R/Pr B R Pb Pr H H - V V - 4.4 Status lights of LED OFF/STAND BY The LED indicator shows solid RED when the projector is off and at standby mode. ON The LED indicator is off when the projector is on. ERROR The LED indicator is blinking at a 0.25 second interval when there is error occurred in projector.
4. Input & Communication 4.5 Connecting the projector to other devices HDMI connection Signals from image source offer the best projection image quality when sent through HDMI. Therefore, try to use input devices with HDMI output as the source of image.
4. Input & Communication VGA connection Connect your PC or other devices with VGA output to the VGA input connectors on the projector to be used as the source of image input.
4. Input & Communication RGBs connection If the source equipment uses composite image synchronized connectors to output VGA, please connect the green, blue and red connectors to the Y, Pb, Pr jacks at the YUV1 inputs and the synchronized output to the VIDEO jack. Green Blue Red DVD player or other SCART RGBS input sources IR INPUT connection If the projector is unable to pick up the IR signals from the remote controle due to distance or obstacles (i.e.
4. Input & Communication COMPONENT connection Take the 3/5 cabled RGB component video connectors from the source equipment to the projector’s YUV1 or RGBHV/YUV2 jacks.
5. Getting Started 5. GETTING STARTED Overview • • • • • • • • • • RCU & Local keypad Using the Remote Control and OSD Lite on Screen Power on projector Switching to standby Power off projector Range of effective remote control signal reception Source selection Changing OSD language Adjusting the lens by horizontal and vertical lens shift Introduction the OSD Lite on screen 5.
5. Getting Started Hotkey / Short Cut Remo result RCU Lite ->OSD Lite action -> on screen to quick adjust a blurry screen mute picture and sound on the projector unmute picture and sound on the projector > press any key Main menu is on screen.
5. Getting Started 5.3 Power on projector How to power on. Press the power switch at the back of the projector to switch on this projector. - When ’0’ is pressed, the projector is switched off. When ’1’ is pressed, the projector is switched on. The projector starts up in standby. When the projector is turned off, it is required to wait for at least 90 seconds to re-start the projector to complete the cooling of lamp. Starting image projection via the standby key.
5. Getting Started 5.6 Range of effective remote control signal reception The diagram below illustrates the range of effective remote control signal reception. 40° 25 m 40° 25 m void placing the remote control at places of high temperature or humidity as it could cause the remote A control to malfunction. 5.7 Source selection Press on the remote control to activate OSD Lite on Screen, then select " on the keypad to select the input source. 32 " for the desired source.
5. Getting Started 5.8 Changing OSD language By factory default, the OSD menu of the projector is displayed in English. If you wish to switch to a different language, Press on the remote control , select the language you prefer for the OSD. 5.9 Adjusting the lens by horizontal and vertical lens shift Via the remote control directly Press the button on the remote control, then select " vertical position of the lens.
5. Getting Started 5.10 Introduction the OSD Lite on screen Press on RCU or press "Home" on projector rear cover, You can see the OSD Lite on screen as above picture. INPUT LENS ZOOM Use this function to select the input souce. You can choice HDMI1, HDMI2, VGA, YUV1 and RGBHV/YUV2. Refer to page 37: 7. INPUT for futher message. Use this function to zoom in or zoom out the image's size. BRIGHTNESS Adjust the level of black in the image to increas or decrease image brightness. Refer to page 41: 8.
6. Introduction the Advanced OSD menu 6. ADVANCED OSD MENU The advanced menu only available for Professional use. Need enter the password to use this function. Overview The Advanced menu is the further function to control and align the projector, the following functions can be done: • Advanced OSD introduction. • Input setup: different Input settings can be adjusted such as specific input slot settings, locking, native resolution and no signal settings.
6. Introduction the Advanced OSD menu 6.2 How to navigate in the Advanced menu structure? Once in the Advanced menu structure, use the or key on the remote control or on the local keypad to scroll through the items in the displayed menu. The selected item will get a background color. To activate a selected submenu or function, press on the remote or OK on the projector. When on a submenu, to return one step to the parent menu, press HOME. .
7.Input 7. INPUT Overview • • • • • • • Input menu overview Input Selection Input Locking Auto Power Off Auto Power On No Signal Auto Image Adjust 7.
7.Input 7.2 Input Selection Use this function to specify the source of image connected to the rear of the projector. For instance, if you have connected your PC as the video input source, you can choose RGB D-15(RGB-HV/SOG) to be the input for image projection. Options of input available on the projector include: HDMI1, HDMI2, RGB D-15(RGB-HV/SOG), YUV1(RGB-S), YUV2(RGBHV/ YUV2). 7.
7.Input If you enable PIP, the projector will automatically synchronize the frequency of the PIP input signal with the main input signal. 7.5 Auto Power Off The default value is OFF. If you set it to ON, the projector will automatically shut down after 20 minutes without input signal. 7.6 Auto Power ON The default value is Off.If you set it to ON, the projector will automatically start up when it is connected to AC power.
8.Image 8. IMAGE Overview • • • • • • • • • • Image menu overview Contrast Brightness Sharpness Noise Reduction Color Temperature Input Balance Aspect Ratio Timings Auto Image 8.1 Image menu overview Contrast 0~200 Brightness 0~200 Sharpness 0~200 Noise Reduction 0~200 Color Temperature 3200K 5400K 6500K 9300K Native Input Balance Black Balance Offset Red Offset Green Offset Blue Offset White Balance Red Gain Green Gain Blue Gain Aspect Ratio 5:4 4:3 16:10 16:9 1.88 2.
8.Image PJWU-101B 8.2 Contrast The contrast function is used to adjust the contrast between the light and the dark areas of the displayed image. It applies a gain to the red, green and blue signals. Contrast adjustment can be done with the Contrast key on the RCU or via the menu structure. The following image illustrates the results of direct contrast adjustment using a random image: Lowered contrast Original image Enhanced contrast 8.
8.Image 8.4 Sharpness The adjustment of sharpness primarily changes the value of high frequency detail. You can connect the projector to an external image source to display an image resembling the one shown below to adjust the image sharpness. The following image illustrates the results of direct sharpness adjustment using a random image: Reduced sharpness Original image Enhancedsharpness  8.5 Noise Reduction Use to adjust the noise of the projected image.
8.Image 8.7 Input Balance Unbalanced color signals When transporting signals, there is always a risk of deterioration of the information contained in the signals. In case of information contained in the amplitude of the signals which is the case of data color signals (R, G, B),image 9-29 , we are quite sure that the amplitude of these color signals is subject to alterations.
8.Image Black level setting : brightness White level setting : contrast The same absolute black and white level for the three colors allows the same reference for Brightness and Contrast control of the picture ! These two references also set the range in which the ADC will work for that particular source (this explains also why each input balance setting is linked to a particular source and thus saved in the image file).
8.Image Black Balance Offset This function involves the adjustment of the following red, green and blue offsets. The text itself is decorative. • Red Offset Press to adjust the offset of red in dark scales. • Green Offset to adjust the offset of green in dark scales. Press • Blue Offset Press to adjust the offset of blue in dark scales. White Balance This function involves the adjustment of the following red, green and blue gains. The text itself is decorative.
8.Image Native input 4:3 Output aspect ratio 5:4 Output aspect ratio 4:3 Output aspect ratio 16:9 Output aspect ratio 1.88 Output aspect ratio 2.
8.Image H Start Use to adjust the projected image’s horizontal position. If the projected image is not at the center of the screen (i.e. shifted to right or left) and ends up being cropped, use this function to adjust the image’s horizontal position.The following image is an example of test image from an external signal source: Native picture Skewed left Skewed right V Phase Use to adjust the projected image’s phase.
9.Layout 9. LAYOUT Overview • Layout menu overview • Zoom • Main Select • PIP Select • PIP Position • PIP 9.
9.Layout 9.2 Zoom Due to the fact that some consumers may still be using older television systems, some TV programs may not display the edges of the image. Use this function to hide the image edge by choosing one of the following three options: • Off Setting it to off makes no change to the projected image. • Crop Setting it to "Crop" will add two "masks" equivalent to 3% of horizontal resolution on either side of the image and two similar masks above and below the projected image.
9.Layout 9.4 PIP Select Use this function to select the source for the sub window. You can choose from HDMI1, HDMI2, VGA, YUV1, RGBHV/YUV2. Sub picture Main picture PiP stands for "Picture in Picture" and allows to display multiple windows containing each of them an image. The windows may be of the video or data type. 9.5 PIP Position Top Left Top Right You can choose to display the sub window in five different location over the main picture according to your preference.
10.Lamp 10. LAMP Overview • • • • • • • Lamp menu overview Lamps Single and Dual setup High Altitue Mode setup Power saving setup Lamp1 and Lamp2 on or off setup Lamp1 and Lamp2 Run Time display Lamp Performance 10.1 Lamp menu overview LAMPS Mode Eco Normal Power LAMPS Single Dual High Altitude Mode On Off Power 77.3% - 100% Lamp1 Status On Off Lamp2 Status On Off Lamp1 Run Time XX HRS Lamp2 Run Time XX HRS 91.
10.Lamp 10.2 Mode This chapter covers information on the projector lamp. Mode When the lamp is set to ECO mode, the lamp is running at 360W. If the ambient temperature is higher than 35 degree Celsius, lamp will operate at ECO mode. In this case, lamp mode selection is unavailable. Lamp mode selection is available once the ambient temperature drops below 35 degree Celsius. • ECO When set to Eco mode, the wattage of the lamp will be at 360W.
10.Lamp 10.4 High Altitude Mode Use this function to control the projector's cooling fan. You can set it to Off or On. The default setting is Off. Under normal circumstances, the projector will operate normally with this function set to Off. By default, the projector will detect the temperature of the surrounding environment to regulate the speed of the cooling fan.
11.Alignment 11. ALIGNMENT Overview • • • • • • • • • Alignment menu overview Adjusting screen orientation(Rear Projection, Ceiling Mode on of off setup) Lens Control for zoom, focus and V/H Shift setup Keystone adjustment Dynamic Contrast setup Gammy adjustment Internal Patterns setup Color space select Setup lens to midposition 11.1 Alignment menu overview Rear Projection On Off Ceiling Mode On Off Lens Control Zoom Focus Shift V/H Keystone Enter Dynamic Contrast On Off Gamma 1.8 2.0 2.2 2.
11.Alignment 11.2 Adjusting screen orientation By default, the projector is configured for “frontal projection - desktop installation”. If you choose to install your projector in other setups, be sure to adjust the screen orientation to achieve the correct projection mode. Front projection - ceiling mode Press HOME Advanced ALIGNMENT Ceiling Mode and choose ON; the projector is now configured for “frontal projection - ceiling mode”.
11.Alignment 11.4 Ceiling Mode The default setting is Off. Whenyou have set up the projector for ceilingmode (hung from the ceiling in reverse), please set it to ON. Refer to page 55: 11.2 Adjusting screen orientation 11.5 Lens Control Zoom Use this function to zoom in or zoom out the image size. Refer to page 15: Lens zoom. Focus Use this function to adjust the image Focus. Refer to page 15: Lens focus Shift Use this function to adjust the lens shift. Refer to page 16: Lens Shift. 11.
11.Alignment 11.8 Gamma Different Gamma settings will affect viewers' perception of the image. Generally speaking, for images that are darker, it is recommended that Gamma be set higher to yield better image quality in darker regions by sacrificing details in brighter areas. In contrast, when projecting brighter images, you can set the Gamma lower to give up details in the darker areas to make the brighter areas (i.e. clouds) more visible. You can choose from five different gamma settings (1.8, 2.0, 2.
12.Control 12. CONTROL Overview • • • • • • • • • Control menu overview ECO Network Power setup Network address setup OSD Menu position Projector start up display Logo or not Projector start up Chime on or off Setup the trigger Setup the projector auto select the source or not Setup the Advanced menu's language 12.
12.Control 12.2 Eco Network Power The projector can be connected to a network via its RS-232 port and 10/100 BASE-T port for remote operation with two separate boards to control the signal sources from RS-232 and 10/100BASE-T ports. If you do not require remote operation of the projector over a network, it is recommended that you set this function to On to activate the ECO Network Power. This will turn off the power that is used to control the 10/100 BASE-T board.
12.Control IP Address Internet Protocol. The network layer of TCP/IP. Required for communication with the internet. Can only be used with a wireless network module installed. Subnet mask A number that is used to identify a subnetwork so that IP addresses can be shared on a local area network. Can only be used with a wireless network module installed. Subnet for Wired and Wifi must be different ! Gateway A router that serves as an entry point into and exit point out of a network.
13.Service 12.5 Start Up Logo You can use this function to have the projector display the Barco logo in the start up screen. Set On to display the Barco logo during start up and Off to display a blank image. 12.6 Start Up Chime Set it to On to have the projector play a sound effect during start up; when it is set to off, the projector will not play any sound effect to indicate start up. 12.7 Trigger1 ~2 The projector comes with two sets of Trigger output.
13.Service 13. SERVICE Overview • Service menu overview • Use this function to display the projector's message. 13.
13.Service 13.2 Service message of the projector The functions covered in this unit relate to the display of some basic information about the projector. Memory of the custom timing files will be erased in the Factory Reset operation • • • • • • • • • • Model: the designated model number of the projector. Serial Number: the designated serial number of the projector. Software Version: the version of software installed on the projector. Active/PIP Source: displays the current PIP sources.
14.Lamp and Filter Maintenance 14. MAINTENANCE 14.1 Lamp Replacement The lifecycle of ordinary projection lamp typically lasts for 1500 hours before requiring replacement (different lamp configurations will affect lamp life). From the OSD Menu, you can go to " page 53: 10.8 Lamp1 Run Time ". to check how long a lamp has been used. You should also replace the lamp when the projected image gets noticeably darker. Contact your local dealer to purchase new certified lamps for your projector.
14.Lamp and Filter Maintenance 4. Use a screw driver to loosen the screws as shwon in the illustration. 5. Pull the lamp out. 6. Insert the new lamp in the direction shown in the illustration into the lamp assembly; tighten the two screws using a screw diver and make sure the lamp is firmly secured to prevent the lamp from shaking or poor contact. 7. Replace the lamp cover and firmly secure the four screws on the lamp cover.
14.Lamp and Filter Maintenance 8. Reconnect power to the projector and reset the lamp usage timer. Refer to page 53: 10.8 Lamp1 Run Time and page 53: 10.9 Lamp2 Run Time hile starting up the projector, the electronics detect if a lamp is installed. If no lamp is installed, it is not W possible to start up the projector. 14.
14.Lamp and Filter Maintenance 2. Take out the old filter. 3. Insert new filter. White side Black side 4. Tighten the six screws of right side cover.
14.Lamp and Filter Maintenance How to change the filter in the Left and Front side. 1. Loosen the six screws on the projector left side cover. 2. Take out the old filter(left and front). 3. Insert new filter.
14.Lamp and Filter Maintenance 4. Tighten the six screws of left side cover. 14.3 Clean the dust filter(for outlet Ventilation) 1. Remove most contamination with a vacuum cleaner. 2. Blow remaining dust away with compressed air in an other room or outside. 14.4 Cleaning the lens T o minimize the possibility of damage to optical coatings, or scratches to lens surfaces, we have developed recommendations for cleaning.
14.Lamp and Filter Maintenance C AUTION: Do not use fabric softener when washing the cleaning cloth or softener sheets when drying the cloth. Do not use liquid cleaners on the cloth as doing so will contaminate the cloth. Other lenses can also be cleaned safely with this Toraysee TM cloth. 14.5 Cleaning the exterior of the projector How to clean the exterior of the projector ? 1. Switch off the projector and unplug the projector from the mains power net. 2.
14.Lamp and Filter Maintenance Problem The remote control does not operate normally You are able to turn on the projector and access the OSD Menu but no picture appears. The image is too bright or the bright areas are blurry Possible cause Solution 1. The battery might have run out 1. Replace new batteries 2. Y ou might have inserted the batteries in the wrong orientations 2. Make sure the batteries are inserted in the right orientation. 3. You may be operating the remote control 3.
15.Projector Specifications 15. PROJECTOR SPECIFICATION 15.1 Specifications Description Specifications Projector type Technology Color Wheel Resolution Brightness* Brightness (eco-mode)* Contrast ratio Brightness uniformity ANSI Aspect Ratio Lens type single-chip DLP projector 0.96'' DMD 6S standard (RGBYCW) WUXGA 1920x1200 10000 ANSI lumen 7500 lumens 1250 : 1 85% 16:10 J lens R9832762: 2.4-4.0:1 R9832761: 1.56-1.85:1 R9832760: 1.85-2.4:1 R9832763: 0.84-1.
15.Projector Specifications PC Apple Mac SECAM SDTV EDTV HDTV PJWU-101B 17/10/2014 640×480 640×480 640×480 800×600 800×600 800×600 848×480 848×480 1024×768 1024×768 1024×768 1280×720 1280×1024 1280×1024 1280×1024 1400×1050 1600×1200 1920×1080 1680×1050 1920×1200 1920×1200 RB 1920×1200 RB 640×480 832×624 SECAM (M) RGBS 1440x480i 1440x576i 480i 576i 480p 576p 1035i 1080i 1080i (Aus) 1080i 1080i 720p 720p 720p 1080p 1080p 1080p 1080p 1080p 1080p 1080p 1080p 59.94 74.99 85 60.32 75 85.06 47.95 59.
15.Projector Specifications 15.
16.Environmental information 16. ENVIRONMENTAL INFORMATION 16.1 Disposal information Disposal Information Waste Electrical and Electronic Equipment This symbol on the product indicates that, under the European Directive 2002/96/EC governing waste from electrical and electronic equipment, this product must not be disposed of with other municipal waste. Please dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
76 "X" ( ( ( , , ) “ ) ) RoHS O O X O O O O O O O O O O O X X X X X X O O X X X X X X ROHS Hg Pb O O O O O O X X O O O O O O O O O O O O O O O O O O O Cr(VI) RoHS ( SJ/T11363-2006 O SJ/T11363-2006 Cd O O O O O O O O O O O O O O PBB O O O O O O O O O O O O O O ), PBDE 16.
16.Environmental information 16.3 Production address Factories Barco nv Entertainment Division Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.82.11 Fax: +32 56.36.883.86 Support: www.barco.com/esupport Visit us at the web: www.barco.
