User guide

7. Important information
MDRC-2224 WP
Product acronym
MDRC-2224 WP
Screen technology TFT Color LCD IPS
Active screen size (diagonal) 611.3 mm (24.1”)
Active screen size (H x V) 518.4 mm x 324.0 mm (20.41” x 12.76”)
Aspect ratio (H:V)
16:10
Resolution
2MP (1920 x 1200)
Pixel pitch 0.270
Color imaging
Yes
Gray imaging
Yes
Color support
10 bit
Viewing angle (H, V) 178°
Ambient Light Compensation
(ALC)
Yes, preset values in OSD
Front sensor Yes
Maximum luminance
300 cd/m² typical
DICOM calibrated luminance 180 cd/m²
Contrast ratio
1000:1 typical
Responsetime(Tr+Tf)
14 ms typical
Housing color
White + Silver
Video input signals
VGA, DisplayPort, HDMI
USB ports
1 upstream, 2 downstream
USB standard
2.0
Power requirements (nominal)
100-240 V
Power consumption (nominal) 40 W (<1.0 W in stand-by)
Power save mode Yes
Power management
DPMS
Dot clock 165 MHz
OSD languages English, French, German, Spanish, Italian, Dutch, Japanese, Traditional
Chinese, Simplified Chinese, Korean
Dimensions with stand (W x H
xD)
560.4 x 533 x 166.35 mm
Dimensions w/o stand (W x H
xD)
560.4 x 366 x 61.72 mm
Dimensions packag
ed (W x H
xD)
481 x 273 x 761 mm
Net weight with stand 9.5 kg
Net weight w/o stand 6.17 kg
Net weight packaged with
stand
13.5 kg
Height adjustment range 100 +/- 5.0 mm
Tilt -5° / +20°
Swivel -45° / +45°
Pivot Yes
Mounting standard VESA (100 mm)
Screen protection Protective, non-reflective glass cover
