User guide

7. Important information
Power requirements (nominal)
100-240 V
Power consumption (nominal) 40 W (<1.0 W in stand-by)
Power save mode Yes
Power management
DPMS
Dot clock 165 MHz
OSD languages English, French, German, Spanish, Italian, Dutch, Japanese, T raditional
Chinese, Simplified Chinese, Korean
Dimens ions with stand (W x H
xD)
560.4 x 533 x 164.45 mm
Dimensions w/o stand (W x H
xD)
560.4x366x59.82mm
Dimensions packaged (W x H
xD)
481 x 273 x 761 mm
Net weight with stand 8.38 kg
Net weight w/o stand 5 kg
Net weight packaged with
stand
12.38 kg
Height adjustment range 100 +/- 5.0 mm
Tilt -5° / +20°
Swivel -45° / +45°
Pivot Yes
Mounting standard VESA (100 mm)
Screen protection N/A
Certifications CE (MDD 93/42/EEC class I product), CE - 2004/108/EC, IEC 60601-1
(ED.3), ANSI/AAMI ES 60601-1:2005 + C1:2009, CAN/CSAC22.2
No. 60601-1-1-08:2008, DEMKO - EN 60601-1-1: 2006, EN
60601-1-2:2007, KC, VCCI, FCC class B, ICES-001 Level B, FDA Class
I device, RoHS
User Guide
Cable routing strap
Video cables (1 x VGA + 1 x HDMI + 1 x DP)
Main cables (UK, European (CEBEC/KEMA) or USA (UL/ CSA; adaptor
plug NEMA 5-15P))
USB 2.0 cable
Supplied accessories
This adapter(s) is a forming part of the medical device.
(Manufacturer: BridgePower Corp.; model: BPM060S12F03; Input:
100-240 V AC, 50-60 Hz, 1.5 A; Output: +12V DC (
), 5.0 A)
QA software QAWeb Private Practice, QAWeb 1.12x
Warranty 3 years
Operating temperature +10°C / +35°C
Storage & transport
temperature
-20°C / +60°C
Operating humidity 10% - 90% (non-condensing)
Storage & transport humidity 5% - 90% (non-condensing) at 39 deg ambient
Oper
ation altitude 3000 m
Sto
rage & transport altitude 5500 m
Ope
rating pressure 70 kPa - 106 kPa
St
orage & transport pressure 50 kPa - 106 kPa
34 K5903081 EONIS 17/06/2014
