Eonis User Guide 24–inch clinical display MDRC-2224 WP MDRC-2224 BL K5903081/02 17/06/2014
Barco nv President Kennedypark 35, 8500 Kortrijk, Belgium Phone: +32 56.23.32.11 Fax: +32 56.26.22.62 Support: www.barco.com/esupport Visit us at the web: www.barco.
Table of contents TABLE OF CONTENTS 1. Welcome! .......................................................................................... 3 1.1 1.2 About the product .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . 3 What’s in the box. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . 4 2. Parts, controls and connectors .....
Table of contents 2 K5903081 EONIS 17/06/2014
1. Welcome! 1. WELCOME! 1.1 About the product Consistent image quality The Eonis display presents crisp, razor-sharp, high-contrast images. To guarantee image consistency at all times, it features a unique front sensor that automatically aligns image quality every time the display is turned on. This image consistency enhances collaboration: images always appear exactly like they are supposed to, on every display, which spurs confident clinical decisions.
1. Welcome! 1.2 What’s in the box Overview Your Eonis comes with: • • • • • • • • • • this Eonis user guide a documentation CD containing multilingual user documentation a system CD containing MediCal QAWeb Agent a (set of) AC power cord(s) (depending on the region of operation) a VGA cable a HDMI cable a DP cable a USB cable an external power supply an accessory bag (cleaning cloth, velcro cable routing strap) Keep your original packaging.
2. Parts, controls and connectors 2. PARTS, CONTROLS AND CONNECTORS 2.1 Front view Overview Image 2-1 1. 2. 3. 4. 5. 6. 7.
2. Parts, controls and connectors 2.2 Rear view Overview Image 2-2 1. 2. 3. 4. 5. 6. 7. 8. 9. 10.
3. Display installation 3. DISPLAY INSTALLATION 3.1 Adjusting the display position To adjust the display position You can now safely pivot, tilt, swivel, raise and lower your display as desired. Image 3-1 The standard orientation of the video input is landscape. If you use the display in portrait mode, make sure you change the orientation of the video input via the screen settings of the computer. WARNING: Put the display in its highest position before pivoting the display.
3. Display installation Image 3-2 3.3 Connecting the cables To connect the cables 1. Connect one or more of the video input connections of your display (VGA, HDMI or DisplayPort) to the corresponding video outputs on your computer or any other video device. 2. If you want to make use of the display’s USB downstream connectors, then connect your workstation with the display’s USB upstream connector by means of the supplied USB cable. 3. Connect a speaker, amplifier, ...
3. Display installation 3.4 Re-attaching the cover To re-attach the connector compartment cover Put the cover back in position by sliding it downwards so that it is fixed to the display again. Pay attention that all cables stay in the cable channel while re-attaching the cover. Image 3-4 3.5 Routing the cables To route the cables 1. Slide the cable routing strap through the opening in the back of the stand. 2. Bundle all cables together so that they will fit in the strap. 3.
3. Display installation Image 3-6 3.7 VESA-mount installation To mount the display on a VESA arm The display panel, standard attached to a stand, is compatible with the VESA 100 mm standard. 1. Put the display face down on a clean and soft surface. Be careful not to damage the panel screen. 2. Unscrew the four fixation screws to detach the panel from the stand. 3. Use 4 M4 screws to attach the panel to a VESA approved arm.
3. Display installation CAUTION: Use suitable mounting apparatus to avoid risk of injury.
3.
4. Daily operation 4. DAILY OPERATION 4.1 Recommendations for daily operation Optimize the lifetime of your display Enabling the Display Power Management System (DPMS) of your display will optimize its lifetime by automatically switching off the backlight when the display is not used for a specified period of time. By default, DPMS is enabled on your display, but it also needs to be activated on your workstation. To do this, go to “Power Options Properties” in the “Control Panel”.
4. Daily operation 4.2 On/Off switching To switch your display on or off 1. Shortly press the Standby ( 4.3 ) key. Bringing up the OSD menus About the OSD menu The OSD menu allows you to configure different settings to make your Eonis display fit your needs within your working environment. Also, you can retrieve general information about your display and its current configuration settings through the OSD menu. To bring up the OSD menu 1. While the display is switched on, press the Menu/Enter ( ) key.
5. Advanced operation 5. ADVANCED OPERATION 5.1 Video input source selection About video input source selection By default, your Eonis display automatically detects and shows the connected video input source. However, when for instance more then one video input source is connected, it may be needed to manually select the input source to be displayed.
5. Advanced operation • • • • • Native: If you select Native, the native panel behavior will not be corrected. sRGB: This is the display function as defined in the sRGB specification and is designed to match typical home and office viewing conditions. It is widely used in most computer applications. DICOM: DICOM (Digital Imaging and Communications in Medicine) is an international standard that was developed to improve the quality and communication of digital images in radiology.
5. Advanced operation To select the white point 1. Bring up the OSD main menu. 2. Navigate to the Adjustments menu. 3. Enter the White Point submenu. 4. Select one of the available white point presets. 5.6 Analog video settings The following settings are only available when VGA video input source is selected.
5. Advanced operation 2. Navigate to the Adjustments > Settings menu. 3. Enter the Language submenu. 4. Select one of the available languages. 5.
5. Advanced operation 5.10 Self calibration frequency About self calibration The front sensor of your Eonis display measures the output luminance of your screen and allows the display to automatically stabilize its luminance for maximum image quality over the displays’ lifetime. This self calibration is done at an adjustable, predefined frequency: • • • • • • 1 min 1 hr 6 hr 24 hr Never QAWeb: This setting will be automatically selected when the self calibration frequency is defined by MediCal QAWeb.
5.
6. Maintenance 6. MAINTENANCE General maintenance information The Eonis does not require any scheduled maintenance or calibration activities. We recommend to use QAWeb with the Barco default tests and frequencies to calibrate and maintain the display or return the display to a Barco approved maintenance organization. In any case of doubts, contact the Barco Healthcare Division 6.
6.
7. Important information 7. IMPORTANT INFORMATION 7.1 Safety information General recommendations Read the safety and operating instructions before operating the device. Retain safety and operating instructions for future reference. Adhere to all warnings on the device and in the operating instructions manual. Follow all instructions for operation and use. Electrical Shock or Fire Hazard To prevent electric shock or fire hazard, do not remove cover. No serviceable parts inside.
7. Important information To fully disengage the power to the device, please disconnect the power cord from the AC inlet. Power cords: • • • • Do not overload wall outlets and extension cords as this may result in fire or electric shock. Mains lead protection (U.S.: Power cord): Power cords should be routed so that they are not likely to be walked upon or pinched by items placed upon or against them, paying particular attention to cords at plugs and receptacles.
7. Important information 7.2 Environmental information Disposal Information Waste Electrical and Electronic Equipment This symbol on the product indicates that, under the European Directive 2012/19/EU governing waste from electrical and electronic equipment, this product must not be disposed of with other municipal waste. Please dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
7. Important information 零件项目(名称) 有毒有害物质或元素 Component name Hazardous substances and elements 汞 六价铬 铅 镉 Pb Hg Cd Cr6+ 塑胶外壳 O O O O 多溴联苯 多溴二苯 醚 PBB PBDE O O Plastic enclosure 散热片(器) O O O O O O Heatsinks 电源供应器 X O O O O O Power Supply Unit 风扇 O O O O O O Fan 文件说明书 O O O O O O Paper Manuals 光盘说明书 O O O O O O CD manual O: 表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T 11363-2006 标准规定的限量要求以下.
7. Important information FCC class B This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
7. Important information This Eonis complies with appropriate medical EMC standards on emissions to, and interference from surrounding equipment. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Interference can be determined by turning the equipment off and on.
7. Important information Immunity test IEC 60601 Compliance level Test levels Radiated RF 3 V/m IEC 61000-4-3 80 MHz to 2.5 GHz 3 V/m Electromagnetic environment – guidance equipment should be used no closer to any part of the Eonis, including cables, than the recommended separation distance calculated from the equation applicable to the frequency of the transmitter. Recommended separation distance d = 1.2√P d = 1.2√P 80 MHz to 800 MHz d = 2.3√P 800 MHz to 2.
7. Important information These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people. Recommended separation distance The Eonis is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled.
7.
7. Important information Indicates this device must not be thrown in the trash but must be recycled, according to the European WEEE (Waste Electrical and Electronic Equipment) directive Indicates Direct Current (DC) Indicates Alternating Current (AC) Stand-by Equipotentiality Symbols on the box On the box of the device, you may find the following symbols (nonrestrictive list): Indicates a device that can be broken or damaged if not handled carefully when being stored.
7. Important information 7.6 Legal disclaimer Disclaimer notice Although every attempt has been made to achieve technical accuracy in this document, we assume no responsibility for errors that may be found. Our goal is to provide you with the most accurate and usable documentation possible; if you discover errors, please let us know. Barco software products are the property of Barco. They are distributed under copyright by Barco N.V. or Barco, Inc.
7. Important information Power requirements (nominal) 100-240 V Power consumption (nominal) 40 W (<1.0 W in stand-by) Power save mode Yes Power management Dot clock DPMS 165 MHz OSD languages English, French, German, Spanish, Italian, Dutch, Japanese, Traditional Chinese, Simplified Chinese, Korean Dimensions with stand (W x H 560.4 x 533 x 164.45 mm x D) Dimensions w/o stand (W x H 560.4 x 366 x 59.82 mm x D) Dimensions packaged (W x H 481 x 273 x 761 mm x D) Net weight with stand 8.
7. Important information MDRC-2224 WP Product acronym MDRC-2224 WP Screen technology TFT Color LCD IPS Active screen size (diagonal) 611.3 mm (24.1”) Active screen size (H x V) 518.4 mm x 324.0 mm (20.41” x 12.76”) 16:10 Aspect ratio (H:V) Resolution Pixel pitch 2MP (1920 x 1200) 0.
7. Important information Certifications Supplied accessories CE (MDD 93/42/EEC class I product), CE - 2004/108/EC, IEC 60601-1 (ED.3), ANSI/AAMI ES 60601-1:2005 + C1:2009, CAN/CSAC22.2 No. 60601-1-1-08:2008, DEMKO - EN 60601-1-1: 2006, EN 60601-1-2:2007, KC, VCCI, FCC class B, ICES-001 Level B, FDA Class I device, RoHS User Guide Cable routing strap Video cables (1 x VGA + 1 x HDMI + 1 x DP) Main cables (UK, European (CEBEC/KEMA) or USA (UL/ CSA; adaptor plug NEMA 5-15P)) USB 2.
A. Troubleshooting A. TROUBLESHOOTING A.1 Troubleshooting General If you experience trouble with the LCD display, refer to the following troubleshooting. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on the screen • • • Push the standby button. Check if all I/O and power connectors are correctly connected as described in the “installation” section. Make sure the pins of the connectors are not crooked or broken.
A. Troubleshooting Problem: Out of range This message means that the signal of the computer graphics card is not compatible with the display. When the signal is not included in the compatibility mode we have listed in the appendices of this manual, the display will show this message.
