Product Manual

Page 4 of 23
Intended Use
Bannon’s 2000-Lb. Telescoping Gantry Crane allows one operator to hoist heavy items easily. It’s
designed for use with a trolley hoist (not included). This crane features an I-beam that adjusts from
99" to 148"H with 9 positive stops to provide a sturdy overhead lift point for lifting car engines, heavy
machinery, and other equipment. The easy crank handle allows for raising and lowering without
difficulty. It rolls smoothly on 5" ball bearing casters (2 locking).
Packaging Contents
 Part A (2)
 Part B
 Rod (1)
 Other parts
 I-Beam (1)
Technical Specifications
Property
Specification
Load Capacity (lb.)
2,000
I-Beam Length (ft.)
7 7/8
I-Beam to Ground (in.)
99 ½ to 148 H
I-Beam H x W (in.)
4 3/4 x 3
Crane L x W (in.)
94 x 58
Product Weight (lb.)
490
Material
Heavy-duty, All Steel Construction
Important Safety Information
⚠WARNING
 Read and understand all instructions. Failure to follow all instructions may result in serious injury
or property damage.
 The warnings, cautions, and instructions in this manual cannot cover all possible conditions or
situations that could occur. Exercise common sense and caution when using this tool. Always be
aware of the environment and ensure that the tool is used in a safe and responsible manner.
 Do not allow persons to operate or assemble the product until they have read this manual and
have developed a thorough understanding of how it works.
 Do not modify this product in any way. Unauthorized modification may impair the function and/or
safety and could affect the life of the product. There are specific applications for which the product
was designed.
 Use the right tool for the job. DO NOT attempt to force small equipment to do the work of larger
industrial equipment. There are certain applications for which this equipment was designed. This
product will be safer and do a better job at the capacity for which it was intended. DO NOT use
