Parts List
Reference
Part Number
Part Description
Qty.
Remark
1
01
Post Insert
2
2
02C
Post Sleeve (left)
1
3
02CB
Post Sleeve (right)
1
4
03
Base
2
5
04C
I-Beam
1
6
05
Post Support
4
7
06C
Winch Box (left)
1
8
06CB
Winch Box (Right)
1
9
07
Height Pin
2
10
08C
Handle
2
11
09C
Swivel Caster
2
5”
12
09DC
Locking Swivel Caster
2
5”
13
10
Cable
2
4*2800
14
10-1
Wire Rope Clamp
4
4KTH
15
11
Caster Bolt
16
M10*25
16
12C
Fixed Bolt
4
M6*10
17
13C
Nut
16
M10
18
14
Post Support Bolt
8
M12*45
19
15C
Rod
1
20
16C
Nut
24
M12
21
17
Post Bolt
8
M12*110
22
18
R-Pin
2
4"
23
19
Washer 12
24
24
20B
Pulley
2
25
21
Pulley Bolt
2
M10*35
26
22
Bracket
2
27
23
Inner Support
4
28
24
Support Bolt
8
M6*8
29
25
Bracket Bolt
2
M8*50
30
26C
Fixed Shaft
2
31
27C
Nut
2
M8
32
28
Washer 6
8
33
29
Beam Bolt
8
M12*40
34
30C
R-Pin
2
2.5"
Replacement Parts
For replacement parts and technical questions, please call Customer Service at 1-800-222-5381.
Not all product components are available for replacement. The illustrations provided are a convenient
reference to the location and position of parts in the assembly sequence.
When ordering parts, the following information will be required: item description, item model number,
item serial number/item lot date code, and the replacement part reference number.
The distributor reserves the rights to make design changes and improvements to product lines and
manuals without notice.
