Installation Manual

YEAR MODEL DESCRIPTION
DOES MY COVER
NEED ANGLE SHIMS?
WHERE DO I
POSITION THEM?
DO MY RAILS NEED
SPACER SHIMS?
CHEVY / GMC /CADILLAC
88 - 98 C/K (All Bed Sizes) Yes Flush With Bottom Edge On Truck Rail Yes - Only On Trucks With Painted Rails
99 - 06 Silverado/Sierra (6’ 6” & 8’ Bed Sizes) Yes Flush With Bottom Edge On Truck Rail Yes - Only On Trucks With Painted Rails
04 - 06 Silverado/Sierra Crew Cab (5’ 8” Bed Size) Yes
Flush With Bottom Edge On Truck Rail -
Under OEM Bed Cap
No
07 - 13 Silverado/Sierra (Also: 2014 HD models) Yes Flush With Bottom Edge On Truck Rail
Yes - Only On Trucks With Painted Rails
14 - 16 Silverado, Sierra No — No
93 - 04 S-10, Sonoma Yes Flush With Bottom Edge On Truck Rail Yes - Only On Trucks With Painted Rails
04 - 13 Colorado, Canyon Yes Flush With Bottom Edge On Truck Rail Yes - Only On Trucks With Painted Rails
15 - 16 Colorado, Canyon Yes
Flush With Bottom Edge On Truck Rail -
Under OEM Bed Cap
No
02 - 13 Avalanche, Escalade EXT No — No
DODGE/RAM
94 - 01 Ram Yes Flush With Bottom Edge On Truck Rail Yes - Only On Trucks With Painted Rails
02 - 08 Ram Yes Flush With Top Edge On Truck Rail Yes - Only On Trucks With Painted Rails
09 - 16 Ram (w/o Ram Box Cargo Mgmt) Yes Flush With Top Edge On Truck Rail No
99 - 11 Dakota No — Yes - Only On Trucks With Painted Rails
FORD
97 - 14 F-150 Yes
Flush With Top Edge On Truck Rail -
Pre-applied at Factory
No
15 - 16 F-150 Yes
Flush With Top Edge On Truck Rail -
Pre-applied at Factory
No
2017 Super Duty Yes Flush With Top Edge On Truck Rail No
99 - 16 Super Duty No — No
93 - 11 Ranger Yes Flush With Bottom Edge On Truck Rail Yes - Only On Trucks With Painted Rails
06 - 13 Sports Trac No — No
HONDA
05 - 15 Ridgeline No — No
NISSAN
00 - 04 Frontier No — Yes - Only On Trucks With Painted Rails
05 - 16 Frontier No — Yes - Only On Trucks With Painted Rails
2016 Titan XD Yes Flush With Top Edge On Truck Rail No
04 - 15 Titan No — No
TOYOTA
96 - 04 Tacoma No — Yes - Only On Trucks With Painted Rails
05 - 16 Tacoma No — No
00 - 06 Tundra No — No
07 - 16 Tundra Yes Flush With Top Edge On Truck Rail No
SPACING & SHIMMING SHEET
