User Manual

Instruction manual

LED PL 2G11

Bailey part numbers:

80100038470, 80100038471, 80100038472, 80100038473, 80100038474, 80100038475, 80100038476, 80100038477

LED 2G11 lamp is suitable to replace 2G11 compact uorescent lamps in xtures with standard non-shunted 2G11 lamp

holders.

This guide contains important information regarding installation and operation. Read these instructions completely and

carefully.

www.bailey.nl

Installation instructions

Magnetic ballast - Conventioneel VSA - Konventionell Vorschaltgerät - Ballast conventionnel

• Always remove starter! - Starter altijd verwijderen - Starter immer entfernen - Retirez toujours starter

• Disconnecting magnetic ballast is optional, not necessary - Loskoppelen magnetische ballast is optioneel, niet nodig

- KVG Trennen ist optional, nicht erforderlich - Déconnecter ballast magnétique est facultative, pas nécessaire

STAR TER

Electronic ballast - Elektronisch VSA - Elektronisch Vorschaltgerät - Ballast electronique

• Disconnect ballast before use! - Ontkoppel de ballast voor gebruik - Trennen Sie das Vorschaltgerät zum Betrieb -

déconnecter le ballast pour une utilisation

B AL LA ST

Connection LED 2G11 lamp

• Rewire as picture - Sluit aan als afbeelding - verkabeln als Bild - recâbler comme image

INPUT

AC176-265V

50/60Hz

PAGE 1
Instruction manual LED PL 2G11 Bailey part numbers: 80100038470, 80100038471, 80100038472, 80100038473, 80100038474, 80100038475, 80100038476, 80100038477 LED 2G11 lamp is suitable to replace 2G11 compact fluorescent lamps in fixtures with standard non-shunted 2G11 lamp holders. This guide contains important information regarding installation and operation. Read these instructions completely and carefully.
PAGE 2
Installation information: Power must be switch off before installation, mound it in the corresponding connection base. Other Cautions: 1. Before installation please read the specifications to make sure that this product is suitable for the operating environment. 2. Please check if the power supply is suitable before use. 3. Make sure that the power supply is switched off before installing to prevent an electric shock. 4. Operation against rules may damage your property even harm to your personal safety. 5.
