Historical Readings
The example shown above displays the collected readings when the Historical Reads schedule is run. Multiple readings for a
single endpoint are displayed for the date listed. The Primary boxes are not checked and no usage and exception conditions
are shown on this screen.
Column Headings
The following headings display in the first three columns in the Readings section of the Collected Readings screen.
Endpoint Serial # Unique serial number of the endpoint.
Read Date Date and time of the meter reading.
Read The actual (raw) meter reading collected at the date and time specified.
Usage and exception conditions reported by the endpoint are listed across the top of the screen in the Readings section. A
check mark in the box indicates a condition that existed at the time of the meter reading.
OTE:N Refer to "Reports" onpage30 for additional information.
Program Endpoint received a program parameter change. For example, it was reprogrammed via IR.
Device Conditions indicated in extended status. See “Device“ under "Status" onpage29.
Tamper Endpoint reporting a tamper condition.
Reverse Endpoint reporting that the encoder measured flow in the reverse direction.
No Use Endpoint reporting no usage.
Leak Endpoint reporting a potential leak condition.
Low Batt Endpoint reporting that its estimated battery life is low.
Primary The Primary indicator is only checked for the endpoint current reads. Current reads are collected when
the Current Reads schedule runs.
Number of
gateways
Number of
readings
