Large Reports
A maximum of 18 fields can be displayed on a report. They display in the following format.
Field 1 Field 2 Field 3 Field 4 Field 5 Field 6
Field 7 Field 8 Field 9 Field 10 Field 11 Field 12
Field 13 Field 14 Field 15 Field 16 Field 17 Field 18
When grouping fields vertically, use the Filler description to create a blank field. In the example below, Filler was used in
Field 6 and Field 14.
Desired format:
Route ID House # Endpoint Type Read Code 1 High Limit Filler
Account ID Street Name Endpoint Serial # Trouble Code Low Limit Read Date/Time
Last Name Filler Meter Serial # Reader Initials Present Read Read Type
Shown below is an example of the Custom Reports screen with the maximum number of fields (18) defined, including two
blank fields.
Click View Selected Accounts at the bottom of the Custom Reports window. Then click Preview to see a report preview, print
the report or export the report file.
