GAS METER DRIVE ROTATION
The table below displays the drive gear rotation direction for common gas meter makes/models.
CW = clockwise
CCW = counter clockwise
Gas Meter ORION Type Direction of Rotation
Elster®/American
AC-250 AMCO Res CCW
AL-425 AMCO Res CCW
AC-630 AMCO Res CCW
AC-800 AMCO Res CCW
AL-800 AMCO C&I CW
AL-1000 AMCO C&I CW
Itron®/Actaris®
Metris 250 Itron/ActarisRes CCW
400A Itron/ActarisRes CCW
675A Itron/Actaris C&I CW
800A Itron/Actaris C&I CW
1000A Itron/Actaris C&I CW
Sensus®
Cubix 250 Sensus Res CCW
R275 Sensus Res CCW
R315 Sensus Res CCW
415 Sensus 415 CCW
750 Sensus C&I CCW
1000 Sensus C&I CCW
GAS METER DRIVE ROTATION
