HOT KEYS, QUICK KEYS, READ KEYS
The handheld software includes a number of Hot Keys and Quick Keys that provide meter reading shortcuts.
Hot Key Press and hold the Fn key – then quickly press and release the hot key to perform the desired function.
Release the Fn key after releasing the hot key.
Example: Press and hold Fn, then press B to bookmark an account.
Quick Key Double or single press the alpha key (depending on Settings) for the desired function to perform.
Example: To change the route reading direction, press DD on the keypad. To change the route reading
direction back, press DD again.
Read Key Several functions can be performed with a single key press only when the account read screen is in use.
They are displayed in the Read Screen (last) column in the table below.
Key Hot Key Function Quick Key Function
(double/single press)
Read Screen
On-screen Usage
A
-- Auto-mode
B
BOOKMARK Toggle bookmark --
C
-- Next bookmark
D
RD DIRECT Toggle route reading direction
E
RESEQ Resequence (not active)
F
RTSTART Route start
G
--
H
HI/LO View High/Low Reads for
current account
I
--
J
-- Encoder error processing
K
SETTINGS Settings
L
-- Flashlight
M
MAN RD Manual read entry
N
MESSAGE Next Next account
O
-- Read extended comment from
ReadCenter
P
-- Previous Previous account
Q
PROGRESS Progress
R
RD CD Reader code
S
SEARCH Search
T
TRBL CODE Trouble code
U
UNREAD Next unread
V
--
W
NXT SKIP Next skipped
X
--
Y
--
Z
SKIP Toggle skipped
9
Toggle screen on and off
OTE:N See "Program Options" onpage50 to change from double press to single press when using quick keys.
