Flashlight
Depending on the configuration, the handheld may include a camera. The dual LEDs for the camera flash can also be used as
a flashlight.
Tap Windows Start> Flashlight to toggle the Flashlight on and off.
Programming a Keypad Button for Flashlight
Any of the buttons on the top row of the handheld keypad (Windows Start, LEFT, RIGHT, CLEAR) or the circle shortcut
button can be programmed to act as the flashlight button.
OTE:N A button can be programmed for one function only.
1. Go to Windows Start> Settings> Personal> Buttons.
2. Tap to select the button you want to assign to the ashlight.
3. Tap in the Assign a program eld and select Flashlight.
4. Tap OK. The button is assigned and will turn the ashlight on and o when pressed.
OTE:N For additional details about programming a keypad button, see "Programming a Barcode Scan Button" onpage67.
Task Manager
The Task Manager is useful for manually closing a program that may not be responding.
Tap Windows Start> Task Manager.
Tap the program you want to close. Then tap End Task or tap Menu > End All Tasks.
TRIMBLE RANGER 3 HANDHELD OVERVIEW
Page 69 April 2014 ORION® Field Application for Trimble® Ranger 3
