15
BT7524
PRODUCT DIMENSIONS
THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO
LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT.
120mm
4.7"
24mm
0.9"
INTERFACE PLATE
45mm
1.8"
64mm
2.5"
10mm
0.4"
6mm
0.2"
O
8.5mm
0.3"
6.5mm
0.3"
WALL PLATE
R 56mm
(2.2")
R 49.5mm
(1.9")
114mm
4.5"
75mm
3"
100mm
3.9"
114mm
4.5"
75mm
3"
100mm
3.9"
