B-TECH AUDIO VIDEO MOUNTS

www.btechavmounts.com

CONTENTS

INSTALLATION TOOLS REQUIRED

FEATURES

BT7524

FLAT SCREEN WALL MOUNT

WITH TILT AND SWIVEL

INSTALLATION GUIDE & PARTS LIST

This Pack Contains 1 Mount

Installation Safety Notes.....................................................................................................................2

Parts List.............................................................................................................................................4

Installation Instructions.......................................................................................................................6

Additional Mounting Options.............................................................................................................13

Product Dimensions..........................................................................................................................14

B-Tech Contact Details.....................................................................................................................16

PLEASE KEEP THIS FOR FUTURE REFERENCE

Community Design Nos.

001713280-0009

001713280-0017

Crosshead

screwdriver

Drill

Pencil

Stud finder

(optional)

8mm (5/16") masonry bit

or 4mm (5/32") wood bit

● Designed for flat screens up to 32” (81cm) / 20kg (44lbs)

● Fits 75 x 75mm, 100 x 100mm

and 200 x 100mm VESA mounting patterns

● Mounts screens 100mm (3.9“) from wall

● Tilts +17°, -10° and swivels 50° (depends on screen size)

● Allows 360° rotation of screen in any direction to display

screen in landscape or portrait style

● Features post installation screen levelling

● Simple hook-on installation with all mounting

hardware included

● Supplied with pin hex security screws for added security

COMPATIBLE

Summary of content (16 pages)

PAGE 1
BT7524 FLAT SCREEN WALL MOUNT WITH TILT AND SWIVEL INSTALLATION GUIDE & PARTS LIST This Pack Contains 1 Mount COMPATIBLE PLEASE KEEP THIS FOR FUTURE REFERENCE FEATURES ● ● ● ● ● ● ● ● Designed for flat screens up to 32” (81cm) / 20kg (44lbs) Fits 75 x 75mm, 100 x 100mm and 200 x 100mm VESA mounting patterns Mounts screens 100mm (3.
PAGE 2
INSTALLATION SAFETY INSTRUCTIONS CAUTION: This wall mount is intended for use only with the maximum weights indicated. Use with flat screens heavier than the maximum indicated may result in instability causing possible injury. Do not attempt to install this product until all instructions and warnings have been read and properly understood. Please keep these instructions for future reference.
PAGE 3
CS Společnost B-Tech International Ltd. doporučuje provést instalaci tohoto produktu prostřednictvím odborného instalátora AV či jinak způsobilé osoby. Společnost B-Tech International Ltd, její distributoři a prodejci nenesou odpovědnost za škody nebo zranění způsobená nevhodnou instalací. Tento výrobek je nutno umístit do vhodné konstrukce a používat jen po uvedenou maximální výšku. DE B-Tech International Ltd.
PAGE 4
BT7524 PARTS LIST 9 3 1 5 6 11 10 7 4 2 11 13 14 12 WALL PLATE & TILT BRACKET ASSEMBLY 15 8 Suitable for loads up to 20kg (44lbs) 4 8
PAGE 5
REF WALL FIXING KIT (FOR FIXING MOUNT TO WALL) A1 A2 A3 19 PART NAME QTY 1 WALL PLATE 1 2 LEFT COVER 1 3 RIGHT COVER 1 4 U-PIECE 1 5 M8 LARGE WASHER 1 6 TILT BRACKET 1 7 INTERFACE PLATE 1 8 ADAPTOR ARM 2 9 M8 x 50mm PIN HEX SECURITY SCREW 1 10 M8 x 30mm SPACER 1 11 M8 PLASTIC WASHER 4 12 M8 x 12mm PIN HEX SECURITY SCREW 2 13 M8 METAL WASHER 2 14 M8 NYLOC NUT 1 15 M4 x 8mm PIN HEX SECURITY SCREW 4 16 2.
PAGE 6
INSTALLATION INSTRUCTIONS 1 Fix wall plate to the wall using one of the following methods. i. Brick / concrete walls.
PAGE 7
ii. Wood / stud walls.
PAGE 8
SCREENS WITH M8 FIXINGS H Screw parts H into the flat screen fixing holes. Continue with screen mounting steps 2 and 3. H H 2 There are two methods of attaching the mount to the screen, depending on the screen fixing pattern. A) VESA Fixings: 75 x 75mm or 100 x 100mm (page 8) B) VESA Fixings: 200 x 100mm (page 9) A VESA Fixings: 75 x 75mm or 100 x 100mm. i. Attach interface plate to back of the screen.
PAGE 9
B VESA Fixing: 200 x 100mm i. Fix the adaptor arms to the interface. 16 7 15 8 ii. Attach interface to back of the screen.
PAGE 10
3 Hook screen onto wall plate.
PAGE 11
4 Secure in position and adjust tilt. 13 12 19 FLAT SCREEN -10° +17° 13 12 5 Levelling the screen.
PAGE 12
6 Optional - Storage for hex keys. 19 OPTIONAL ACCESSORIES B-Tech AV Component Shelves & Cable Management.
PAGE 13
ADDITIONAL MOUNTING OPTIONS This product is compatible with the System 2 range of professional install products from B-Tech Pole Installations The BT7524 can swivel up to 130° when mounted on a vertical pole.
PAGE 14
BT7524 PRODUCT DIMENSIONS MOUNT WITH ADAPTOR ARMS 114mm 4.5" 17° 88mm 3.5" 126mm 5" 79mm 3.1" 100mm 3.9" 10° MOUNT WITHOUT ADAPTOR ARMS 108mm 4.3" 17° 110mm 4.3" 82mm 3.2" 126mm 5" 75mm 3" 93mm 3.7" 10° INTERFACE PLATE WITH ADAPTORS 200mm 7.9" 100mm 3.9" 120mm 4.7" 220mm 8.7" 14 THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT.
PAGE 15
BT7524 PRODUCT DIMENSIONS INTERFACE PLATE 100mm 3.9" 75mm 3" 100mm 3.9" 75mm 3" 114mm 4.5" 114mm 4.5" WALL PLATE R 56mm (2.2") R 49.5mm (1.9") 64mm 2.5" O 24mm 0.9" 10mm 0.4" 120mm 4.7" 8.5mm 0.3" 6.5mm 0.3" 6mm 0.2" 45mm 1.8" THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT.
