Foreword Congratulations on your new investment. You chose one of the best high-tech, GPS enabled, mobile radar and laser detector available on the market today. The Radenso Pro M-Edition is the evolution of the Radenso equipped with an additional circuit designed to detect the newest Multaradar and Gatos RT 3 delivering astonishing detection range on all radar bands. Coupled with multiple filters against annoying false alerts your Radenso Pro M-Edition will alert only when it counts.
To start using your Radenso Pro-M radar detector follow these easy steps: 1. Slide the windshield mounting bracket into the QuickMount slot at the front of the radar detector. 2. Plug the small end of the power cable into the power jack on the Radenso Pro-M on the left side and connect the large plug with the 12V power socket in your car. 3. Press the red button at the large end of the power cable (at the 12V socket) to turn the power cable on. The button will light up and indicate if Power is on. 4.
Power/Menu Botton Short press: You will enter into setup menu. During an alert pressing the button mutes the volume. The next alarm will be reported again with the Default volume. Long press: Turn unit ON / OFF. Volume Buttons [+ -] Short press: Changing volume of the Radenso Pro-M or change program options in the Menu Mode. Release Button Press this button and slide the windshield mount until it is locked. Press button to unlock the mount for removal.
The Radenso Pro-M windshield mount allows a firm and secure installation of the radar detector at the windshield of your vehicle. Locate an area at the windshield that enables an unobtrusive installation with clear view to the road ahead. 1. Place the nipple of the suction cups in the the bracket and pull the suction cup into the small Rubber hole to secure them. Push the rubber into the hole in the middle of the bracket. large hole of Damper damper 2.
Smart Dark: Display is deactivated but will come on with text warning during an alert. Full Dark: Display is completely deactivated. Only voice and tone alerts are active. Long Press: Holding the button for 2 seconds during an obvious false alert will lockout the location in the future. The signal will then be reported and the alarm suppressed when passing the market location again. You can reactivate the location again by holding the button when approaching the marked location.
The AutoCity driving mode allows the setting of minimum alert detection speed for signal suppression and signal filtering resulting in significantly reduced false alerts. Select AutoCity in Setting Mode. Setting AutoCity speed: (feature selectable only if Setting Mode is set to AutoCity): Tapping the Middle button lets you select the speed for editing Left speed setting indicates the speed below which the radar reception of the detector will be complete ly disabled (in example above 20 mph).
The detector lets you mark known false alert areas so that you will not receive audio alerts in the future at the marked location. The detector stores the GPS coordinates as well as radar band, radar frequency and signal strength and compares it each time with the actual signal received. If the received signal at the lockout location is different from the saved signal in terms of frequency and/or signal strength the detector automatically unmutes and you will be alerted by audio again.
Operating Frequency: GPS: SiRF STAR IV Ka narrow: 33.80, 34.7, 35 5 GHz (± 120 MHz) Ka Wide: 33.4 GHz - 36.0 GHz K narrow: 24.1 GHz (± 70 MHz) K wide: 24.1 GHz (± 150 MHz) X band: 10.525 GHz (± 50 MHz) Laser: 904mm FCC COMPLIANCE Operating Frequency: Operating temperature: -30° - +180 ° F (-20° - +85° C) Operating voltage: 11-16 V Energy consumption: 250 mA normal, 330 mA max. (12V) Dimensions: 2.44 x 3.62 x 1.
ONE (1) YEAR LIMITED WARRANTY RADENSO warrants, for two years, to the original retail owner, this RADENSO product to be free from defects in materials and craftsmanship with only the limitations or exclusions set out below. WARRANTY DURATION: This warranty to the original user is valid for 12 months after the date of original retail sale.
