OPERATING INSTRUCTIONS
5 VDC Output
The 5 Vdc is a fixed voltage supply providing up to 500 mA (0.5 amp)
continuous. The 5 Vdc output is available at the two right OUTPUT 5V tie
points. Be sure to observe polarity.
1. The  12V  and  5V  supplies  will  provide  up  to  1  amp
for  a  short  period,  but  thermal  shutdown  may occur
when the output is overloaded for  a few minutes.
Upon thermal shutdown there will be now  output.  If
thermal  shutdown  occurs,  remove  the  load  and  wait
15 minutes for  the power supply  to cool.  Normal
operation may then resume.
2. Overloading May also cause sever ripple I the output
which could disrupt operation  of the circuit  being
powered.  Excessive  ripple  will  produce  a  loud  hum
in devices with speakers.
3. You  can  prevent  overloading  by  measuring  the
output  current  with  an  external  multimeter. Set  the
meter to measure current (a 2 amp range is desirable,
or  a  10  amp  range  may  be  used)  and  connect  is
"series"  with  the  load.  Load  current  up  to  500  mA
may be  operated continuously, load  current greater
than 500 mA must be short term,  maximum short
term current is 1 amp.
DUAL OR TRIPLE OUTPUT
Two  of  the  outputs,  or  all  three  of  the  outputs  may  be  used
simultaneously if desired. The three outputs are fully isolated from ground,
and each other, thus each output may be connected for the either positive
or negative polarity.
A typical example of a triple output application would be powering a
circuit board that requires three voltages, such as +5, +12V and -12V. Fig.
4  shows  how  the  outputs  would  be  connected  for  this  example,  and  the
following procedures reviews the steps of hook-up.
1. The  variable  supply  would  be  set  for  12V.  WE  will  assign  the
variable supply as the  +12V source and the  fixed  12V supply  as
the -12V source.
2. Connect the - terminal of the 5V supply to circuit board common
and the + terminal to the +5V input of the board.
3. Connect the  - terminal  of the  variable supply  to circuit  board
common  (or  the  terminal  of  the  5V  supply).  Connect  the  +
terminal of the variable supply to the +12V input of the board.
4. Connect  the  +  terminal  of  the  fixed  12V supply  to  circuit  board
common (or  the  -  terminal of  the  5V and  variable supplies).
Connect the - terminal of the fixed 12V supply to the -12V input
of the board.
CONNECTING OUTPUTS IN SERIES
When  the  30  volt  output  of  the  variable  supply  is  not  adequate,  the
outputs  may  be  connected  in  series  to  provide  a  variable  17  to  47  volt
output. Since the supplies are connected in series, the maximum current is
the same  as for  the fixed  voltage  supplies,  that,  500  mA  continuous  or 1
amp peak. Connections for the configuration are shown in Fig. 5.
CAUTION
