CONTROLS AND INDCATORS
1. POWER Switch. Turns power supply on and off.
"I" : power switch ON
"O" : power switch OFF
2. Power ON light. Lights when power is turned on.
3. CURRENT LIMITED Indicator. Lights when variable
supply is operating in constant current mode.
4. CURRENT Control. Adjusts maximum output current of
variable supply. Read value on A meter
5. VOLTAGE Control. Adjusts output voltage of variable
supply. Read value on V Meter.
6. A Meter. Indicates output current of variable supply.
7. V Meter. Indicates output voltage of variable supply.
8. OUTPUT + Terminal (Red). Positive polarity output
terminal.
9. OUTPUT - Terminal (Black). Negative polarity variable
output terminal.
10. 12V OUTPUT + Terminal (red). Positive polarity 12 VDC
output terminal.
11. 12V OUTPUT - Terminal (black). Negative polarity 12 VDC
output terminal.
12. 5V OUTPUT - Terminal (black). Negative polarity 5 VDC
output terminal
13. 5V OUTPUT + Terminal (red). Positive polarity 5 VDC
output terminal.
14. POWER Input connector
15. FUSE Holder
16. DC Fan
