Instruction manual

Thank you for choosing a B&D automatic garage door
opener. This automatic garage door opener has been
designed and developed in Australia by B&D Doors.
The technically advanced construction of this B&D
opener ensures you enjoy the following benefi ts:
Warranty
Five (5) year/10,000 cycles full parts and labour
warranty on motor, electronics and mechanical
components of the opener when installed by an
authorized B&D Dealer (conditions such as having the
garage door serviced annually also apply).
Tri-Tran Frequency Hopping Technology
Every time a transmitter is used, it simultaneously
sends a signal over three different frequencies,
reducing the chance of interference from other radio
frequency sources.
Code Hopping Technology
Every time a transmitter is used a new security
code is generated from over 4.29 billion possible
combinations.
Multi-Channel Transmitter
Multi-channel transmitters allow you to operate other
devices such as an adjoining garage door or automated
gate from the same handy unit.
Soft Start/Soft Stop
The opener eases into and out of each cycle for smooth
and quiet operation, and also to reduce wear on the door
and opener.
Safety Reversing System
Automatic safety reverse ensures personal protection
from death or serious injury if trapped under a door
while closing. Safety reverse force can be adjusted for
environmental conditions, for example windy areas,
etc.
LED Courtesy Light
Taking advantage of the latest advances in Light
Emitting Diode (LED) technology, which produces a
brilliant white light to illuminate the garage.
The LED courtesy light automatically switches on for
approximately 4 1⁄2 minutes (time programmable)
when operating the door. This can also be programmed
to turn on and off from a remote control transmitter.
Manual Release
Emergency manual release handle for manual
operation of the door in the event of a power failure.
Memory Retention
In case of a power failure the opener does not lose the
transmitter codes or limits settings.
Self Locking
No need to manually lock your garage door, as the opener
‘positively’ locks the door when closed.
Periodic Maintenance Indicator
The opener has a built in counter with a default setting
of 3000 cycles. When the counter expires the opener will
beep and fl ash to indicate a service is required.
Service Fault Indicator
Flashing LED’s on the control panel easily identify
operational problems or service requirements.
Safety Beam Failure Emergency Close
When a safety beam prevents movement due to any reason
other than a ‘real’ obstruction, the user can secure their
property by pressing and holding a button on the remote
control or OSC on the console.
Dynamic Door Profi ling
Automatically compensates for changes in door operating
characteristics.
Auto-Close
Auto closing option can be programmed to close the door
approximately 30 seconds after the door has opened. N.B.
Safety Beams must be installed for this option to function.
External Antenna
An external antenna can be connected - for sites where
radio reception is a problem.
Vacation Mode
A transmitter can be programmer to disable the garage
door opener radio receiver. This is ideal if the door is to be
left idle for prolonged periods.
Pet Mode
A transmitter can be programmed to open the door partially
to allow pets access to the garage. The door opening height is
adjustable via a handheld programmer.
Auxiliary Output
You can program a spare button of you remote control
transmitter to operate this output to control items that can
be switched using a momentary close.
Battery Back Up
Optional battery back up or solar power is available.
