Instruction manual

System Specifi cations
Maximum Door Size
3000mm high 5500mm wide (16.5m
2
) residential rolling garage door, or 2400mm
high wind lock residential rolling garage door
Door Load
Rated Load: 550N
Recommended Load: 200N (20kgs).
Ideal Load: 70N (7kgs)
Supply Voltage 230 - 240 V AC 50Hz
Courtesy Light LED (Light Emitting Diode) lighting. Light comes on when door starts, turns off
approx. 4½ minutes later and can be programmed to operate from a remote control
transmitter
Limit Adjustment Electronic
Force Control Electronic - fully automatic. Can be adjusted for environmental reasons
Transmitter Frequency
433.47, 433.92, 434.37 MHz
Coding type Tri-Tran™
Transmitter battery CR2032 (3 Volts)
Powerhead Weight
7.6kg Max.
Door Drum Rotation
3 Turns
Auxiliary Power Supply 24-35VDC at 100mA
Rated Load 550N
Auxiliary Output Transistor output 35V 100mA. Connected to GND when activated
External Aerial Connection
2-Pin Screw Connector
Diamond PD Power Drive : Instruction Manual
© Copyright June 2012 B&D Doors
5Controll-A-Door
®
Diamond PD - Power Drive Instruction Manual
