Instruction manual

How To Use Your Opener
Safety Beam Option
A wired or wireless Safety Beam Kit may be fi tted to
this opener.
• When this option is fi tted, the operation of
this device is such that if an object (i.e. car,
child, etc) blocks the safety beam, then the
garage door opener will not close the door
automatically.
• If the Safety Beam is fi tted but not operating
correctly, then the door once opened
automatically, will not close automatically.
When the door will not close and a fault with
the safety beam is suspected Safety Beam
Failure Emergency Close mode may be used.
Auto Close Option
To have the Auto Close option you must also have
a Safety Beam fi tted and functioning. To enable the
Auto close function remove the light diffuser from the
opener and install the AUTO-CLS jumper.
When this option is selected the garage door opener
will attempt to close the door automatically 30
seconds after opening.
If the Safety Beam is interrupted whilst the door
is closing (e.g. by a person walking through the
doorway), the door will reverse to the fully open
position.
Safety Beam Failure Emergency Close
When a safety beam prevents movement due to any
reason other than a ‘real’ obstruction, the user can
secure their property by pressing and holding a button
on the remote control or OSC on the console.
The transmitter button must be coded for open/
stop/close function. The door will start moving after
continuous activation of remote button or OSC on
console for more than fi ve seconds. Continue holding
the button until the door is closed. Contact a B&D door
professional for a service.
Remote Control Transmitter Battery
When necessary, remove the cover and replace
the battery with the same type. Dispose of the old
batteries properly.
Courtesy Light
The Courtesy Light will illuminate for approximately 4 ½
minutes each time the door is operated automatically.
Spare buttons of multi channel remote control transmitters
or an entry keypad can be programmed to turn the light
on and off by remote control.
Auxiliary Output
This function allows the opener to operate other devices
such as external lights, or an alarm system.
To use this function, a spare button of a multi channel
remote control transmitter (Smart Code or Dip Switch
Code) or an entry keypad, must be programmed to
operate the Auxiliary Output feature.
Vacation Mode
The radio receiver of the garage door opener can be
turned off using a remote control transmitter to activate
the Vacation Mode facility. Whilst in vacation mode the
opener will not respond to any remote control transmitter.
To activate the Vacation Mode facility, with the garage
door in the closed position, press the coded remote
control transmitter for 5 seconds. The Code Set LED
will illuminate to indicate that the opener is in “Vacation
Mode”.
To exit Vacation Mode press the same transmitter button
that was used to activate Vacation Mode until the Code
Set LED turns off.
Pet Mode
A remote control transmitter can be programmed to open
the door partially (approximately 200mm) to allow pet
access to the garage.
To activate Pet Mode press the transmitter button that
has been programmed for Pet Mode - the door will open
partially. Pressing the button again will return the door to
the closed position.
Controll-A-Door
®
Diamond PD - Power Drive Instruction Manual22
