Temperature measurement system
in wall housing
DescriptionDescription
Features
In the building automation budget-priced measuring systems which are
suitable for long-term work and protected against overvoltage and tran
-
sients are needed. Further aspects are the choice between direct
current and alternating current supply, a high long-term stability plus a
good measurement accuracy during the application.
The B+B Temperature probe series –GLT have been developped es
-
pecially for these requirements and are specically suitable for working
in this branche through the most modern sensor technology and the
innovative installation using an ASIC. The measurement of tempera
-
ture occurs with a precise and longterm stable resistance temperature
detector. The processing of the measurement values is linearised and
temperature compensated. The power supply occurs optionally through
alternating curent (AC) and direct current (DC) supply. Due to the big
exchange area and the labelled clamps a simple and fast connection
is warranted.
Technical Data
Characteristic features
• Inconspicoous wall housing
• Standard signal 0...10 V
• Linearised and temperature compensated
temperature measurement
• High long-term stability, innovative technology
• Integrated sensor technology
Areas of application
• Temperature measurement in the inner area
• Building technology
• Industrial measurement and control technology
• Climatic record
• Home Automation
Temperature measurement
Measuring range -30...+70 °C
Accuracy ±0,7 °K (0...40°C)
Output scale -30...70 °C FS
In general
CE-conformity 89/336/EWG
EMV transient emissions EN 61000-6-3:2001
Dimensions see drawing
Housing ABS
Connection screw terminals 0,75 mm²
Operating voltage 12...24 V AC/DC
Overvoltage protector varistor and RC lter
