Temperature module
with Voltage-Output and I²C-Bus
Assignment of I²C output register
Output scaling Pt1000 temperature
Model Byte 0,1 (MSB/LSB) Byte 2,3 Byte 4,5
Pt1000 Temperature ASIC Temperature T2 channel
Typ – R1
0x0000 – 0x7FFF
-32.00 ... +95.9961 °C
Not used Not used
Typ – R2
0x0000 – 0x7FFF
-32.00 ... +223.992 °C
Not used Not used
Typ – R3
0x0000 – 0x7FFF
-32.00 ... +479.984 °C
Not used Not used
Model Output Value range HEX Scaling Formula Increment Accuracy
Typ – R1
I²C:
analog:
0x0000 ... 0x7FFF
0x000X ... 0x3FF
-32,00 ... 95,9961 °C
-32,00 ... 95,9375 °C
T(°C)=V/256-32
1/256 °C
1/16 °C
±0,15 K
Typ – R2
I²C:
analog:
0x0000 ... 0x7FFF
0x000X ... 0x3FF
-32,00 ... 223,992 °C
-32,00 ... 223,875 °C
T(°C)=V/128-32
1/128 °C
1/8 °C
±0,25 K
Typ – R3
I²C:
analog:
0x0000 ... 0x7FFF
0x000X ... 0x3FF
-32,00 ... 479,984 °C
-32,00 ... 479,750 °C
T(°C)=V/64-32
1/64 °C
1/4 °C
±0,5 K
The physical resolution is approximately half of the arithmetical resolution at the output. The actual temperature range is dependent on the sensor
element used.
The accuracy refers to the digital I²C-output of the module in the measuring range center in purchase to the IEC resistance characteristic of the sensor
element.
