Datasheet

DATA SHEET
Technical changes reserved
0141 0316-114 07/2014
DescriptionDescription
Features
• Professional weatherproof housing
• Protection from sun and rain
• Versions with mast clamp, mounting brackets or mounting plate
• Radiation shut Ø 110 x 150 mm
• 10 segments from UV-stabilized white makrolon
• Anodized connection sleeve with M16 cable gland and pressure
compensation membrane
Applications
• Suitable for probes with Ø 12 x 180 mm
• Outdoor installation
• Protection of sensors from the weather
Technical data
Material radiation hat
10 segments from UV-stabilized white
makrolon
Radiation hat Ø 110 x 150 mm
Application temperature -20...+80 °C
Connection Anodized connection sleeve with M16
cable gland and pressure compensation
membrane
Article Art.-No.
Weatherproof housing, with mast clamp 0,5" to 2“
und Ausleger 300 mm steel, hot dip galvanized
STRAHUT-
MAST
Weatherproof housing, with mounting bracket,
210 x 85 x 90 mm steel, hot dip galvanized
STRAHUT-
MOWI
Mounting bracket without weatherproof housing,
210 x 85 x 90 mm
0173 0115
Especially outdoor used humidity sensors have to be protected from
sunlight and rain. The weatherproof housing is a thoughtful solution
for protection of the sensor from weather, without the distorting of the
measurement. Special materials which are suitable for outdoor use
ensure lasting durability.
There are various galvanized brackets for safe attachment available:
With mast clamp 0.5“ to 2“, mounting bracket or at mounting plate.
Note: For outdoor using the humidity sensor must be equipped with a
Teon or PE cap.
More weather proof housing with other dimensions are available at
short notice.
Weatherproof housing for protection of
outdoor sensors STRAHUT
B+B Thermo-Technik GmbH | Heinrich-Hertz-Straße 4 | D-78166 Donaueschingen
Fon [phone] | Fax [phone] | [e-mail] | bb-sensors.com
1 / 1
