UNIVERSAL SENSOR SWITCHING MODULE
Instruction manual Page 5
Released 09/2006 Rights reserved for change in technical data! HYGROSENS INSTRUMENTS GmbH Postfach 1054 D-79839 Löffingen Tel: [phone] Fax: [phone]
3 Technical data
General
Operating voltage
Type –230V (156530)
230VAC/5 VA max.
Operating voltage
Type –MOD12V (156503)
12V..15V DC 65 mA max.
11V..14V AC 80 mA max. (without probe)
Operating voltage
Type –MOD24V (156517)
22V..28V DC 45 mA max.
15V..25 V AC 60 mA max. (without probe)
Time delay switch 10 sec to 11 min +/-20%
configurable with jumper plugs
Relay Changeover contact for resistive load
NO contact rating 230V AC / 5A
NC contact rating 230V AC /2 A
Surge suppression Suppression with a Varistor VZ 05/390V
Dimensions Type –230V (156530) 100 x 100 x 60mm
Supply in plastic housing
Type –MOD (156503/17) PCB 95 x 75 x 30mm
Supply only as a PCB
Sensors
DC Impedance input 0..1/10/100 k-Ohm; configurable with jumper plugs
Voltage/Current input 0..1V/10V/20mA, configurable with jumper plugs
AC Impedance input Series impedance 10k..50k
Conductance 30µS..10 µS
Switching input NC/NO or voltage signal 0/5V
4 Ordering information
Swiching device an accessories Ordering No.
Universal Switching module, PCB for 12 V DC 15 65 03
Universal Switching module, PCB for 24 V DC 15 65 17
Switching module 230V, in housing with operating panel 15 65 30
Housing ET210F, unfinished 15 65 44
Probe with connection cable Ordering No.
Dew formation probe 15 65 56
Conductance probe 15 65 70
Space humidity probe 15 65 84
Temperature probe with stainless protection tube 15 65 97
Temperature probe, pressure resistant with screw threads 15 65 04
Light intensity probe, weather proof 15 65 18
Our delivery program is constantly updated!
