Frequently Asked Questions
PleasevisitIcron’swebsiteforanswerstoFAQs: http://www.icron.com/products/usb/faq.php
Specifications
Range 100 meters over CAT 5 (or better) stranded or solid conductor cable
USB device support
High-speed devices (480 Mb/s) (USB 2.0)
Full speed devices (12 Mb/s) (USB 2.0 & 1.1)
Low speed devices (1.5 Mb/s) (USB 2.0 & 1.1)
USB hub support Any single chain can include up to 4 USB hubs plus one Ranger.
USB host support EHCI (USB 2.0) and OHCI/UHCI (USB 1.1)
Maximum USB devices
supported (Incl. USB Hubs)
14 USB Devices including any additional USB hubs connected to the REX.
AC adapter(s)
Use only the AC
adapter provided
Input: 100/240 V AC, 50 – 60 Hz
Output: 5 V DC, 1.5 A
AC adapter connector 8-pin Icron custom connector
Power available to USB
device at REX unit
500 mA
USB cable length (LEX to
Host computer)
0.15 meters (0.49 ft)
LEX unit USB connector 1 x USB Type A connector
LEX unit Link connector 1 x RJ45
REX unit Link connector 1 x RJ45
REX unit USB connector 1 x USB Type A port
LEX unit dimensions 44 mm x 87 mm x 24 mm (1.72” x 3.43” x 0.95”)
LEX unit weight 0.06 kg ( 0.13 lbs)
LEX power consumption 500 mA Maximum
REX unit dimensions 44 mm x 87 mm x 24 mm (1.72” x 3.43” x 0.95”)
REX unit weight 0.05 kg ( 0.11 lbs)
REX power consumption Approx. 500 mA (No Load). 1A (Full load)
System shipping weight 0.18 kg (0.40 lbs)
Operating temperature
range
0°C – 50°C
Regulatory testing FCC Class A, IC, CE Class A
ESD rating EMC EN-61000-4-2 4kV Contact, 8kV Air
