User's Manual

- 4 -
2. Block Diagram
3. Specifications Table

Wireless LAN &Bluetooth Module

IEEE 802.11b/g/n, Wi-Fi compliant

Bluetooth 3.0 +high speed complaint with Bluetooth 2.1+Enhanced
Data Rate (EDR)

WLAN and Bluetooth through SDIO
 
Marvell 8787

11mm x 23mm x 2.4mm
!
"!
3.3V/1.8V(optional)+/- 10%
#
Operating: -20 ~ 70
o
C ; Storage: -40 ~ 85
o
C
$
%&'(!
2.4 GHz ISM radio band
)
802.11b: USA, Canada and Taiwan
–
11
Most European Countries – 13
France – 4, Japan – 14
802.11g: USA, Canada and Taiwan – 11
Most European Countries – 13
Japan – 13
802.11n(HT20): Channel 1~14(2412~2484)
802.11n(HT40): Channel 1~7(2422~2472)

DSSS, OFDM, DBPSK, DQPSK, CCK, 16-QAM, 64-QAM for WLAN
GFSK (1Mbps), Ȇ/4 DQPSK (2Mbps) and 8DPSK (3Mbps) for
Bluetooth
*
WLAN:
