CLEANING AND DISASSEMBLE REAR INTERNALS
1. Lift upward on the Top Cocking Knob at the rear of Delrin Bolt.
This will let the Delrin Bolt (P041) slide out from the rear of the
receiver.
2. Turn the End Cap (A051) counterclockwise. This will let the End
Cap and the marker’s internals to slide out from the rear of the
receiver. Remember to place the marker in the de-cock position
and place light pressure behind the End Cap during the removal
of the End Cap, this way will prevent the internals to spring out.
3. Slide the Feather Striker (P021) out of the rear of the receiver.
4. Once all the internal parts are removed, use a squeegee to clean
the inside of the receiver and use a towel to clean the dirt or
paint off of Delrin bolt. Apply some paintball gun oil on the Striker
O-Ring regularly.
