Quick Start Guide

AX-ADDCAM-CH5 AX-ADDCAM-CH5 AX-ADDCAM-CH5
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS
REV. 12/21/17 REV. 12/21/17 REV. 12/21/17© COPYRIGHT 2017 METRA ELECTRONICS CORPORATION © COPYRIGHT 2017 METRA ELECTRONICS CORPORATION © COPYRIGHT 2017 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com
• Control 1 - Gray/Blue wire
• Control 2 - Gray/Red wire
• Control 3 - Orange wire
• Control 4 - Orange/White wire
• Control 1 - Gray/Blue wire
• Control 2 - Gray/Red wire
• Control 3 - Orange wire
• Control 4 - Orange/White wire
• Control 1 - Gray/Blue wire
• Control 2 - Gray/Red wire
• Control 3 - Orange wire
• Control 4 - Orange/White wire
Chrysler 2013-up*
FEATURES
• “Plug & Play” harness for the AX-ADDCAM interface (sold separately)
• Reverse signal trigger generated via CAN bus communication of the
vehicle
• Turn signal trigger generated via CAN bus communication of the vehicle
• (4) Programmable camera control wires (configured through the
Axxess Updater program)
INSTALLATION
• Configure the AX-ADDCAM interface following the installation instructions
included with the AX-ADDCAM interface. Failure to configure the interface
will result in the interface not functioning properly .
CONNECTIONS
• For vehicles with a factory camera: The camera signal will need to be
interrupted and connected to the corresponding input/output RCA jacks
on the AX-ADDCAM interface.
• Connect the RCA jack from the AX-ADDCAM-CH5 labeled “Camera
output”, to the RCA jack on the AX-ADDCAM interface labeled “Camera 1”.
• Connect the RCA jack from the AX-ADDCAM-CH5 labeled “Camera input”,
to the RCA jack on the AX-ADDCAM interface labeled “Camera output”.
• For vehicles without a factory camera: Disregard the RCA jack labeled
“Camera output”, it will not be used in this application. Connect the RCA
jack on the AX-ADDCAM-CH5 labeled “Camera input”, to the RCA jack on
the AX-ADDCAM interface labeled “Camera output”.
• Disregard the following (2) wires, they will not be used in this application :
Blue/Green, Green/Blue
ANALOG CONTROL TRIGGER WIRES
• The optional analog control wires can be activated with either a negative
or positive trigger depending on how they are configured in the Axxess
Updater program. These wires will only be used if manual control of the
cameras will be desired. Otherwise tape off and disregard these wires.
*Visit AxxessInterfaces.com for up-to-date vehicle specific applications.
