User manual

232
"" "" Experimental Log Values
"" "" Print to Log
"" "" Sweeps/Files
"" "" [x] T0 [x] P0 [x] AP0
"" "" [x] T1 [x] P1 [x] AP1
"" "" Protocol Flow, Enter/Leave
"" "" [x] Loop
"" "" [x] AvgLoop
"" "" [x] Run
"" "" [x] Run of Run/ElseRun
"" "" [x] ElseRun of Run/ElseRun
"" "" Detection Values
"" "" AD0
"" "" LowPass Filter - Not used
"" "" Rs not calculated
"" "" S0
"" "" Baseline: 8 to 2 ms before pulse
"" "" Peak: Auto 0 to 15 ms before pulse
"" "" MaxSlope: 2 ms, -2 to 2 ms after pulse
"" "" S1 - Not used
"" "" AD1
"" "" LowPass Filter - Not used
"" "" Rs not calculated
"" "" S0 - Not used
"" "" S1 - Not used
"" "" Dialog Box Values
"" "" SweepFile -> Set ADsweep File Types dialog box
"" "" PulseSweep File Type
"" "" (*) WinLTP's ASCII file format (data columns only)
"" "" TrainSweep - Not used
"" "" AmpFile -> Analyses To Do dialog box
"" "" AD0 AD1
"" "" MainPg AnalysisPg MainPg AnalysisPg
"" "" S0+S1 S0+S1 S0+S1 S0+S1
"" "" [x] [ ] [ ] [ ] DC Baseline
"" "" [x] [ ] [ ] [ ] Peak Amplitude
"" "" [ ] [ ] [ ] [ ] Latency
"" "" [ ] [ ] [ ] [ ] Area
"" "" [ ] [ ] [ ] [ ] Duration
"" "" [ ] [ ] [ ] [ ] Rise Time
"" "" [ ] [ ] [ ] [ ] Decay Time
"" "" [ ] [ ] [ ] [ ] Coastline
"" "" [ ] [ ] [ ] [ ] PopSpike Amplitude
"" "" [ ] [ ] [ ] [ ] PopSpike Latency
"" "" [x] [ ] [ ] [ ] Slope
"" "" [ ] [ ] [ ] [ ] Average Amplitude
"" "" [ ] [ ] [ ] [ ] Rs
"" "" [ ] [ ] [ ] [ ] Rm
"" "" AmpFile -> Slope Calculation Method dialog box
"" "" AD0 AD1
"" "" (*) (*) Maximum Slope
"" "" ( ) ( ) Begin -> End Times
"" "" ( ) ( ) Low% -> High% of Peak Amplitude
"" "" AmpFile -> PopSpike Calculation Method dialog box
"" "" AD0 AD1
"" "" (*) (*) Area
"" "" ( ) ( ) Amplitude
"" "" AmpFile -> Series and Input Resistance dialog box
"" "" Measure Rs and Rm from Normal or Unfiltered Trace
"" "" AD0 AD1
"" "" ( ) ( ) Normal trace (Raw, Averaged, Blanked and/or Filtered)
"" "" (*) (*) Unfiltered trace (default, Raw and/or Averaged)
"" "" Rs Calculation Method
"" "" AD0 AD1
"" "" (*) (*) Peak (default fit)
"" "" ( ) ( ) Single Exponential Fit
"" "" ( ) ( ) Double Exponential Fit
"" "" Extrapolation
"" "" AD0 AD1
"" "" (*) (*) Extrapolate back to TimeZero (start of Rs/Rm pulse, default)
"" "" ( ) ( ) Extrapolate between TimeZero and Rs Peak
"" "" ( ) ( ) No extrapolation, use Rs Peak
"" "" ( ) ( ) In Mohms (using external amplifier's Set/Gated stimulation)
"" "" AD0 -2 mV
Fig. 11.10.3 (middle). All Protocol values printed when the ‘All’ button is clicked. Continued on preceding
and next pages.
