User manual

231
18:40:57.2 0.0 Start MainProtocol
18:40:57.7 0.5 Enter Loop0
18:40:57.7 0.5 09200250.P0, First Loop sweep
""
18:41:10.3 "" All Protocol Values
"" "" Edit Protocol dialog box
"" "" Acquisition/Stimulation Paramters tab
"" "" Analog Input Channels - Acquisition Values
"" "" DataType Gain Units/V mV/Unit
"" "" AD0 Used mV 1000 1mV/V 1000mV/mV
"" "" AD1 Used mV 1000 1mV/V 1000mV/mV
"" "" Acquisition Sample Intervals
"" "" PulseSweeps: 50 us
"" "" TrainSweeps: 50 us
"" "" Continuous Acquisition: 50 us
"" "" Analog Output Values
"" "" DataType Gain Units/V
"" "" IC0 mV 50 20mV/V
"" "" IC1 mV 50 20mV/V
"" "" Continuous Acquisition - Used
"" "" MainProtocol tab
"" "" Start with MainProtocol
"" "" [x] Continuous Acquisition
"" "" Protocol Script Area
"" "" MainProtocol
"" "" [X] Loop [ 6]
"" "" [X] P0sweep [ 5]s
"" "" EndLoop
"" "" EndProtocol
"" "" Enable Sweep Functions
"" "" Pulse Train
"" "" [ ] [ ] Stimulus Artifact Blanking
"" "" [ ] [ ] Low-Pass Filtering
"" "" Evoked Events tab
"" "" Single Pulse or Train Sweep
"" "" [x] P0sweep
"" "" [ ] P1sweep
"" "" [ ] T0sweep
"" "" [ ] T1sweep NumSwps Add
"" "" Fast Repeat Pulse Sweeps (LTD) Avg toAvg Delay
"" "" [ ] P0 [ 30]*[ 2]s=1m [ ] [ ] [ ]
"" "" [ ] P1 [ 30]*[ 2]s=1m [ ] [ ] [ ]
"" "" Fast Repeat Train Sweeps (Theta) AddDelay
"" "" [ ] T0 [ 4]*[ 5]s=20s [ ]
"" "" [ ] T1 [ 4]*[ 5]s=20s [ ]
"" "" Plot/Save tab
"" "" AD Channels to Plot and Save
"" "" Plot SaveToDisk
"" "" Cont Stim Cont Stim
"" "" Acquis Sweep Acquis Sweep
"" "" AD0 [x] [x] [x] [x]
"" "" AD1 [x] [x] [x] [x]
"" "" Save Sweeps to Disk
"" "" Pulse Train
"" "" [x] [x] Raw Sweeps
"" "" [ ] Averaged Sweeps
"" "" [ ] [ ] Stimulus Blanked Sweeps
"" "" [ ] [ ] Low-Pass Filtered Sweeps
"" "" Sweep Stimulation Values
"" "" P0sweep tab
"" "" Sweep Duration = 100 msec
"" "" S0 tab Delay0 Pulse1 Off2
"" "" Pulse Dur (ms) 0.1
"" "" Pulse Interval (ms) 20 50
"" "" Number Pulses 1
"" "" S1 - NotUsed
"" "" IC0 - NotUsed
"" "" IC1 - NotUsed
"" "" P1sweep - NotUsed
"" "" T0sweep - NotUsed
"" "" T1sweep - NotUsed
Fig. 11.10.3 (top). All Protocol values printed when the ‘All’ button is clicked. Continued on next pages.
