11.10 Print Detection, Stimulation or All Protocol Values when their
button is clicked
In WinLTP 1.11 we added the capability to print Detection, Stimulation or All Protocol Values to the
Experimental Log when the ‘Detection’, ‘Stimulation’ or ‘All’ button just below the Experimental Log (see
Fig. 11.1.1) is clicked. This printing will occur while WinLTP is idle, or when the MainProtocol or
ContinuousAcquisition Protocol is running. The first sweep after the Protocol values have been printed is
also printed (see purple sections). In the three examples in this section, no Pulse or Train Sweep
CheckBoxes have been checked, and the Detection, Stimulation and All Protocol Values are for the
default.pro protocol.
Fig. 11.10.1 shows the Detection Protocol Values printed when the ‘Detection’ button is clicked. For each
AD channel, the LowPass Filtering and Rs calculations are shown followed by waveform detection values,
in this case for Baseline, Peak Amplitude and MaxSlope.
18:05:06.2 0.0 Start MainProtocol
18:05:06.7 0.5 Enter Loop0
18:05:06.7 0.5 09200227.P0, First Loop sweep
""
18:05:23.7 "" Detection Protocol Values
"" "" AD0
"" "" LowPass Filter - Not used
"" "" Rs not calculated
"" "" S0
"" "" Baseline: 8 to 2 ms before pulse
"" "" Peak: Auto 0 to 15 ms before pulse
"" "" MaxSlope: 2 ms, -2 to 2 ms after pulse
"" "" S1
"" "" Baseline: 8 to 2 ms before pulse
"" "" Peak: Auto 0 to 15 ms before pulse
"" "" MaxSlope: 2 ms, -2 to 2 ms after pulse
"" "" AD1
"" "" LowPass Filter - Not used
"" "" Rs not calculated
"" "" S0 - Not used
"" "" S1 - Not used
18:05:26.7 20.5 09200231.P0, First sweep after Protocol values printed
18:05:46.7 40.5 Leave Loop0
18:05:46.7 40.5 Stop MainProtocol
Fig. 11.10.1. Detection values (in blue) printed to the Experimental log when the ‘Detection’ button is
clicked, followed by the first sweep after the Detection protocol values are printed (purple).
Fig. 11.10.2 shows the Stimulation Protocol Values printed when the ‘Stimulation’ button below the
Experimental Log is clicked. The information in the MainProtocol tabsheet (including the Protocol Builder
script lines in dark green), the Evoked Events tabsheet, and the P0sweep, P1sweep, T0sweep and
T1sweep tabsheets is printed. The Plot/Save tabsheet values are not printed.
