FF-2S-QR HAMMERHEAD F o l l o w F o c u s Q U I CK-STA RT GU I DE
THANK YOU FOR CHOOSING AXLER. PRECAUTIONS • Please read and follow these instructions, and keep this manual in a safe place. • Make sure that this product is intact and that there are no missing parts. • Use only parts provided by the manufacturer. • Handle the unit with care. • To avoid damage to this product, be careful not to overtighten or improperly thread any of the threaded fittings. • Clean the unit with a soft, dry cloth. • Make sure everything is secure before use.
2 1 3 5 4 7 10 13 6 8 11 12 9 14 OVERVIE W 1. Marking disc: Pull to remove. 2. Focus wheel 3. Stop A: Loosen the screw to adjust. 4. Stop B: Loosen the screw to adjust. 9. Drive gear screw: Use a 3 mm hex wrench to switch the drive gear to the other side of the dual-sided drive. 10. Width adjustment: Accommodates lens diameters from 0.78 to 3.9 inches (20 to 100 mm). 5. Reference marker 11. Width adjustment locking knob 6. Stop A/B release: 12.
ONE-YEAR LIMITED WARRANTY This Axler product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
