Instruction manual
Table Of Contents
- Important Safety Instructions
- Precautions
- DECLARATION OF CONFORMITY
- We declare under our sole responsibility that this product, to which this declaration relates, is in conformity with the following standards:
- EN60065, EN55013, EN55020, EN61000-3-2 and EN61000-3-3.
- Following the provisions of Low Voltage Directive 2006/95/EC and EMC Directive 2004/108/EC, the EC regulation 1275/2008 and its frame work Directive 2009/125/EC for Energy-related Products (ErP).
- A NOTE ABOUT RECYCLING:
- This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with the local recycling regulations.
- When discarding the unit, comply with local rules or regulations. Batteries should never be thrown away or incinerated but disposed of in accordance with the local regulations concerning battery disposal.
- This product and the supplied accessories constitute the applicable product according to the WEEE directive.
- Precautions
- For U.S. models
- For Canadian Models
- 1 Front Panel
- 1 AC Inlet
- 2 Speaker Terminals
- Amplifier Section
- General
Data
Command Content
Standby
(01)
00 – Standby OFF
01 – Standby ON
04 – Toggle
Mute
(02)
00 – Mute
01 – Un-mute
02 – Toggle Mute
Source Selection
(03)
00 – S5
01 – S6
02 – S7
03 – S4
04 – S8
05 – S1
06 – S2
07 – S3
08
09
10
11
12
13
14
40 – S5 Audio only
41 – S6 Audio only
42 – S7 Audio only
43 – S4 Audio only
44 – S8 Audio only
45 – S1 Audio only
46 – S2 Audio only
47 – S3 Audio only
Volume
(04)
00 – A0 range
Bass
(05)
F4 – 0C (-12db - +12db)
Treble
(06)
F4 – 0C (-12db - +12db)
Balance
(07)
EC – 14 (Left –20db – Right –20db)
Send all parameters
(09)
XX – value ignored
Amplifier features
(0C)
00 – Loudness enabled
01 – Loudness disabled
Maximum Volume Limit
(0D)
00 – A0 range
Link Zone
(0F)
00 – 31 zone to be linked
FF – for no zone linking
Volume Up
(11)
XX – value ignored
Volume Down
(12)
XX – value ignored
Zone Name
(1C)
Data field contains the ASCII string
Preamplifier Volume Mode
(1D)
00 – A0 range
FF = Independent mode.
20
