Installation guide

AXIST90BSeries
Distance
AXIST90B20IR-LED
10°x10°-120m(394ft)*
35°x10°-65m(213ft)
60°x25°-45m(148ft)
80°x30°-30m(98ft)
120°x50°-20m(66ft)**
AXIST90B30IR-LED
10°x10°-220m(722ft)*
35°x10°-120m(394ft)
60°x25°-65m(213ft)
80°x30°-45m(148ft)
120°x50°-30m(98ft)**
AXIST90B40IR-LED
10°x10°-310m(1010ft)*
35°x10°-170m(551ft)
60°x25°-112m(367ft)
80°x30°-70m(230ft)
120°x50°-65m(213ft)**
AXIST90B15W-LED
10°x10°-50m(164ft)*
35°x10°-35m(1 15ft)
60°x25°-20m(66ft)
80°x30°-15m(49ft)
120°x50°-10m(33ft)**
AXIST90B25W-LED
10°x10°-90m(295ft)*
35°x10°-55m(180ft)
60°x25°-30m(98ft)
80°x30°-20m(66ft)
120°x50°-15m(49ft)**
AXIST90B35W-LED
10°x10°-150m(492ft)*
35°x10°-80m(262ft)
60°x25°-45m(148ft)
