AXIST90BSeries
1.Turnthelighton(night)andoff(day)automaticallyviathe
photocell.Thisisthestandardfactorysetting,nofurther
actionisrequired.
2.Turnthelightonandofffromaremoteswitchorinput.
3.UsedinconjunctionwiththeTimerFunctiontoturnthelight
onforapre-denedperiodoftime.
Telemetry-DIM
Theremotedimmingfeatureallowsthebrightnessoftheilluminatortobe
controlledremotelyusingthetelemetryinputwires.UsetheDIMbutton
toselectthisfunction.
WhentheDIMfunctionisselected,atelemetryinputintotheilluminator
willvarythebrightnessupanddown.Whenthetelemetryinputisrst
applied,itwillstarttodimthelightandwillcontinuetodosowhilethe
telemetryinputisactive.Whentelemetryinputstops,thelightlevelwill
staywhereitwasset.Whenthetelemetryinputisactivatedforasecond
time,thelightwillstarttobrighten.Thiswillcontinuewhilethetelemetry
inputisactive.Thisactivationandde-activationofthetelemetryinput
willreversethewaythelightisdimmed(dimdownanddimup),toallow
theusertosetexactlythelevelrequired.DisabletheDIMfunctionby
pressingtheTELbutton.
AftersettingaspeciclightlevelusingtheDIMfunction,ifDIMisdisabled
andTELenabled,thelastpowerlevelsetwhenusingtheDIMfunction
willberememberedandusedbythesystemunlessanewpoweradjust
buttonisselected.
Timer
Thetimerfunctionallowstheilluminatortobetriggeredviaatelemetry
inputandremainonforapre-denedperiodoftime.Therearefour
pre-denedtimesandatimerdisablefunction.Toselecttimerfunction,
rstpressandreleasetheTELbutton,thenselectthedurationofthetimer
asshownbelow.
