AXIST90BSeries

•TelemetryTELenabled

•Telemetryinputwiressolderedtogetherforautomatic

photocelloperation

•TelemetryDIMdisabled

•LEDstatusindicatorsenabled

•ProgrammingMode

Note

Changingthesettingsrequiresaremotecontrol(optional

accessory).TheilluminatormustbeinProgrammingMode.

TheilluminatorautomaticallyswitchesfromProgramming

ModetoNormalOperatingModeafter4weeks.Toswitchto

ProgrammingMode,restarttheilluminator.

1.Adjustthepower,seePowerAdjustonpage22.

2.Adjustthephotocellsensitivity,seePhotocellSensitivityon

page22.

3.Setthetelemetryinput:

-TEL,seepage24

-DIM,seepage25

-Timer,seepage25

4.DisabletheLEDstatusindicators,seeLEDStatusIndicators

onpage26.

5.Disableremotecontrolsetup,seeDisableRemoteControl

Setuponpage27.

6.Restorethefactorydefaultsettings,seeFactoryDefaulton

page27.

NormalOperatingMode

TheonlyfunctionoftheRemoteControlavailableduringNormalOperating

ModeisLEDStatusIndicators,seeLEDStatusIndicatorsonpage26.
