AXIST90BSeries

NormalOperatingMode(Continued)

SolidAmberInputvoltagelevelerror*

SolidRed

InternalLEDerror

*Oncethevoltageerrorhasbeencorrected,disabletheremotecontrol

setuporrestarttheilluminatortoturnthestatusLEDoff.

ConnectorsandButtons

Forspecicationsandoperatingconditions,seepage14.

PowerConnector

•AC/DCpowerconnector

Specications

OperatingConditions

ProductTemperatureHumidity

AXIST90BSeries-50°Cto50°C

(-58°Fto122°F)

10–100%RH(con-

densing)

PowerConsumption

ProductValue

AXIST90B15W-LED

12–24VAC/DC,max12W

AXIST90B20IR-LED

12–24VAC/DC,max24W
