Installation guide

AXIST90BSeries
LEDIndicators
TherearethreecoloredLEDindicatorsonthebaseoftheilluminatorwhich
provideoperatingandstatusinformation.Thecolorstatusdependson
thecurrentoperatingmode:
•ProgrammingMode
•NormalOperatingMode
ProgrammingMode
LEDIndicatorIndicatedBehavior
SolidGreen
Poweron
FlashingGreen
RemotecontrolIRreceivererror
SolidAmber
Illuminatorreceivingvalid
commandfromremotecontrol
FlashingAmberIlluminatorinProgrammingMode
SolidRed
InternalLEDerror
FlashingRed
Inputvoltagesupplyerror*
NormalOperatingMode
LEDIndicatorIndicatedBehavior
SolidGreen
Poweron
FlashingGreen
RemotecontrolIRreceivererror
