Exploded View

AXIS AX-M7
69
S+F3/16"*2"
Mach. Screw
1
70
S-S5/16"*3/8”
Screw
2
71
NUT-1/4*20NC
Nut
1
72
NUT-5/16*18NC
Nut
4
73
NUT3/8”*24NF
Nut
1
74
W-3/8
Flat Washer
1
75
W-5/16
Flat Washer
2
76
W-5/16*23
Flat Washer
2
77
SW-1/4
Spring Washer
2
78
SW-5/16
Spring Washer
6
79
11007-01-007
Sticker of Control Panel
1
80
11007-13-001
Back Cover (for CE model only)
1
81
11007-13-002
Front Cover (for CE model only)
1
82
11007-13-003
Seat of Micro Switch (for CE model only)
1
83
11007-13-004
Fixed Ring
1
84
S+R1/8”*3/8”
Mach. Screw
4
85
S-BR3/16”*3/8”
Screw
2
86
S+F5/32”*3/8”
Mach. Screw
4
87
V-155-1A5
Micro Switch
2
91
11007-05-002
Carbon of Motor
2
92
11007-05-003
Carbon Cover
2
93
11007-11-006
Limit Switch Seat
1
