Exploded View

ManualsBrandsAxis ManualsCommercial EquipmentAX-M7 Commercial Mixer with Capacity of 7 Quarts, 3 Speeds, Digital Timer, in Stainless Steel

1

2

3

AXIS AX-M7

ILLUS.

PARTS NO.

PARTS NAME

Q'TY

1

11007-01-001

Top Cover

1

2

11007-01-004

Retainer

1

3

11007-01-005

Mixer Head and Column

1

4

11007-02-001

Center Shaft

1

5

11007-02-003

Gear-Center Shaft

1

6

11007-02-010

Spacer

1

7

11007-04-001

Worm Gear Shaft

1

8

11007-04-002

Worm Gear

1

9

11007-04-003

Gear-Worm Gear Shaft

1

10

11007-05-001

Motor (100-120V) or (200-240V)

1

11

11007-07-001

Control Board

1

12

11007-07-002

IC Board (100-120V) or (200-240V)

1

13

11007-08-001

Planetary Gear

1

14

11007-08-002

Internal Gear

1

15

11007-08-003

Head Ring (for HL-11007 model only)

1

16

11007-08-004

Planetary Head

1

17

11007-08-005

Planetary Shaft

1

18

11007-08-007

Tapered Pin

1

19

11007-09-002

Rear Plate of Column

1

20

11007-09-003

Apron

1

21

11007-09-004

Base

1

22

11007-10-001

Bowl Support

1

23

11007-10-002

Bowl Pin

2

24

11007-11-001

Lifting Bar

1

25

11007-11-002

Fixed Angle Plate

1

26

11007-11-003

Lifting Bracket

1

27

11007-11-004

Lifting Handle

1

28

BM10-11-005

Compression Spring

1

29

11007-12-001

7 Liter Bowl

1

30

11007-12-002

Flat Beater

1

31

11007-12-003

Spiral Hook

1

32

11007-12-004

Wire Whip

1

33

11012-04-008

Cover Plug

2
