User's Manual

Stealth Repeater

- QSG

Power

The Stealth Repeater is powered by one to four lithium-ion batteries. So to make sure

that the batteries are good batteries when they are put in there is a button to test them.

When testing the batteries to see if they are good batteries put them in the Stealth

Repeater. If you put in a battery the wrong way, a red LED light will illuminate saying the

polarity is incorrect.

After putting in all the batteries correctly there are buttons in the lower right hand corner

of the Stealth Repeater. (Refer to Illustration 2 below) One is to test the batteries to see

if they are good or bad batteries. When you press the button a light will illuminate beside

it saying it it testing. As long as this light is lit, the test is still active. If the battery is good

the good light will illuminate and light a green LED.

The lithium batteries have a typical service life in excess of 10 years. In most cases, the

SLA battery will power the Repeater through any power outages and the lithium battery

will last for its expected service life. If an extended power outage drains the lithium

battery, it must be replaced.

Warning:

Lithium-ion batteries are capable of supplying large amounts of power and can

be dangerous if short-circuited. The Repeater circuitry includes a self-

resetting fuse that automatically limits the battery current in the event of a

short circuit, however care should be exercised while handling Lithium

batteries.

Illustration 2
