3
AXICOM
Signal Relays
MT2 Relay
(Continued)
20.2+0.05/-0.02 10.0+0.05/-0.02
0.55
11.0±0.2
3.2±0.3
0.50
7.62±0.15
PCB layout
TOP view on component side of PCB
Terminal assignment
TOP view on component side of PCB
Dimensions Packing
Product code structure Typical product code C934 22
Type
C934 MT2 Series Signal Relay
2 form C, 2 CO, AgNi +Au contacts
Coil
Coil code: please refer to coil versions table
