Axesstel Fixed Wireless Phone CDMA PX130N User Manual
CDMA FWP PX130N INDEX 1 GENERAL INTRODUCTION .......................................................................................................... 1 2 IMPORTANT INFORMATION ........................................................................................................ 2 3 PRODUCT OVERVIEW .................................................................................................................. 3 3.1 PACKING LIST ...................................................................
CDMA FWP PX130N 9.1 SCHEDULE ........................................................................................................................................... 16 9.2 ALARM CLOCK .................................................................................................................................... 16 9.3 CALCULATOR....................................................................................................................................... 16 9.4 UTK ...........................
CDMA FWP PX130N 1 General Introduction Thank you for choosing CDMA Fixed Wireless Phone of Axesstel. To use your phone well, please read this user manual carefully before you use. The phone has been designed to operate with the latest digital communication technology - Code Division Multiple Access (CDMA).
CDMA FWP PX130N 2 Important Information The product can only be installed indoors. Do not place the phone near high temperature objects, under direct sunlight, near source of water, near fire or near inflammable and explosive materials. Avoid using the phone in high temperature or humidity. The phone may interfere with heart pacemaker, hearing aid and other electronic medical devices. Therefore please follow the instructions given by your equipment suppliers or consult your doctor.
CDMA FWP PX130N 3 Product Overview 3.1 Packing List Once you open the product package, please check the packing list to make sure there is no part missing. If any part is missing or broken, please contact the customer service. The packing list is as follow: No. 1 2 3 4 5 6 7 8 9 Name Phone Body Handset Antenna Handset Cable Ni-MH Rechargeable Battery Charger USB Cable CD Disk Prints Qty.
CDMA FWP PX130N 3.2.
CDMA FWP PX130N 3.2.3 Display Icon The following icon may appear on the display of the phone: No. Icon Description Current signal strength. The more bars there are, the stronger the signal is. 1 No signal. 2 Battery capacity indicator. The more bars there are, the more capacity the 3 battery has. Supplied by charger 4 Alarm on 5 Mute 6 No UIM card 8 Unread message 9 Roaming 10 Figure 3 Display Icon 4 Basic Operations 4.1 Installing UIM card 1. Remove UIM bracket cover. 2. Insert proper UIM card. 3.
CDMA FWP PX3x0N 4.3 Make a Call While your phone is power on and at standby screen, enter a destination number you wish to call and then press Key. (Note: To modify digits you enter, you can press Key to delete wrong digits first and then enter new digits).
CDMA FWP PX130N 5 Main MENU Press Left Soft Key Key to enter the main MENU from the standby screen. The main MENU includes: Contacts, Messages, Recent Calls, Tools, and Settings.
CDMA FWP PX130N 2. After finish inputting the text, press to select the Send, Send Messages, Insert Template, Insert Contacts, or Save as Template function. 3. Press <1 Send> to send a message to one recipient， input destination number directly or select numbers from (Contacts), press
CDMA FWP PX130N 6.3 View Outbox 1. In Messages, press to scroll to <3 Outbox> and press
CDMA FWP PX130N <3 Draft>, <4 all>, if you want to delete them, follow the steps above. 6.8 Memory Status In this MENU, you could check the phone memory status and UIM card memory status for messages. In Messages, press to scroll to <8 Memory status>, press to view the status. 6.9 Message Settings You can set Send Mode and Save Position in Msg Settings MENU. 1. In Messages, press to scroll to <9 Message settings>. 2.
CDMA FWP PX130N a) b) c) 7.2 Send Message: Use this number to send a message. Save: Save this number to contacts. Delete: Erase this number in the list. Received Calls 1. In standby screen, press
CDMA FWP PX130N press , to select <4 Reset Time>. 3. Press to select <1 Received Calls>,press to reset received calls time or to cancel the action. Note: You can press to scroll to Dialed calls, All calls .If you want to reset time, follow the steps above. Reset? OK 7.5 Delete Record 1. In standby screen, press
CDMA FWP PX130N to scroll to the desired contact, press to view the contact information. 8.2 Add a New Contact 1. Press
CDMA FWP PX130N Note: You can select <3 Delete All> to delete all contacts in the group or <1 Add New> to add a new contact to the group. 8.4.3 Add a Group There are 5 groups in your phone; You can add more groups. 1. Press
CDMA FWP PX130N No.1 is voice mail number. You can edit the No.02~09 locations. 1. Make sure some contacts exist in phone book. 2. Press
CDMA FWP PX130N 9.1 Schedule You could add your schedule in the phone, to add a schedule, please 1. In standby screen, press
CDMA FWP PX130N 10.1 Tones Tones 1 Ring Tone 2 Volume 3 Alert … Ring Tone 1 In Contacts 2 Not In Contacts 3 Messages Tone1 Tones 1 Ring Tone 2 Volume 3 Alert … Here you can set the ring tone and volume. Press
CDMA FWP PX130N 10.2.2 Backlight In standby screen, Press< MENU >, , <2 Display >, to enter display menu. Select <2 Backlight>, press, you can change the timer of turning Backlight off the backlight, and you also could turn off the backlight by selecting o 7 Seconds Always Off. Press
CDMA FWP PX130N 10.3 Security Select Security in Settings MENU, you will be prompted to enter password; the initial password is “0000”, input the password, press key, then you can enter the security MENU Lock Phone o Unlock o Lock 10.3.1 Lock phone In Security menu, select <1 Lock Phone>, press to select Unlock or lock the phone. Press
CDMA FWP PX130N 10.3.5 Outgoing Call Setting In Security menu, select <4 Outgoing Call Setting>, press to do the Outgoing Call Limit, Outgoing Call Number List or Dial Delay Time operation. 1) Select the Outgoing Call Limit, press , select Permit All, Forbid All, Permit List or Forbid List screen. 2) Select the Outgoing Call Number List, press to edit the Permit List or Forbid List. Press to edit the number list, you can edit 10 numbers in every list. Press to input number.
CDMA FWP PX130N Ring Tone Tones Volume Alert Display In Contacts Not In Contacts Messages Ring Tone Key Beep Handset Handsfree Minute Beep Call Connect Power On/Off Banner Backlight Contrast Language Hyphen Tone 1 Tone 2 Tone 2 Med Low Med Med Off Off On welcome 7 Seconds 2 Espanol Disable 10.4 Call Settings 10.4.1 Auto Answer In Call Settings menu, select <1 Auto Answer>, press . There are 2 options to choose, off and On. You can press, to select.
CDMA FWP PX130N Activate> or <2 Cancel> to enable call forward if busy or disable it. Note: You can select <2 FWD If No Answer> and <3 FWD All Calls> via key, follow the steps above to enable or disable them. 2. Press to select <2 Call Waiting>, press to activate it or cancel it. Call Forward 1 FWD if Busy 2 FWD if No Answer 3 FWD All Calls Select Back Call Waiting 1 Activate 2 Cancel Select 10.6 Phone Info You could check the phone information in this MENU.
CDMA FWP PX130N necessary software has been properly installed and configured. Moisture or ventilation problems: Visually inspect the phone body, moisture can damage the phone. Ventilation is also very important. Move the phone to improve the ventilation as necessary. No power: Verify that AC power source and its corresponding circuit breaker are functioning properly.
FCC statement: Section 15.105 (b) Note: Thi' equipment has been tested and found to complv with the limits fOf a Cia" Bdigrtal device, pUfSuantto pan 15 of the fCC Rufe,. The,e limit, afe de'i~ned to provide 'easonable prote
